INVT Goodrive3000 Series Operation Manual page 242

Goodrive3000 series medium voltage VFD
Function
Name
code
Ramp reference
P17.02
frequency
P17.03 Output voltage 0–4000V
P17.04 Output current
P17.05 Motor speed
P17.06 Torque current -3000.0–3000.0A
P17.07 Exciting current -3000.0–3000.0A
P17.08 Motor power
P17.09 Output torque
Evaluated motor
P17.10
frequency
P17.11 DC bus voltage 0.0–6000.0V
Digital input
P17.12
terminals state
Digital output
P17.13
terminals state
Digital
P17.14
adjustment
P17.15 Torque reference
P17.16 Reserved
P17.17 Reserved
P17.18 Reserved
P17.19 AI1 input voltage 0.00–10.00V
P17.20 AI2 input voltage -10.00–10.00V
P17.21 AI3 input voltage 0.00–10.00V
HDI input
P17.22
frequency
P17.23 PID reference
Description
0.00Hz–P00.03
0.0–3000.0A
0–65535RPM
-300.0–300.0% (the rated current of the
motor)
-250.0–250.0%
0.00–P00.03
0000–00FF
0000–000F
0.00Hz–P00.03
-300.0%–300.0% (the rated current of
the motor)
0.00–50.00kHz
-100.0–100.0%
-237-
Goodrive3000 inverter
Setting range Default
0.00–P00.03 0.00Hz
0–4000 0V
0.0–3000.0 0.0A
0–65535 0 RPM
3000.0–3000.0 0.0A
3000.0–3000.0 0.0A
-300.0–300.0 0.0%
-250.0–250.0 0.0%
0.00–600.00 0.00Hz
0.0–6000.0 0V
0000–00FF 0
0000–000F 0
0.00–P00.03 0.00Hz
-300.0–300.0 0.0%
0.00–10.00 0.00V
-10.00–10.00 0.00V
0.00–10.00V 0.00V
0.00–50.00 0.00 kHz
-100.0–100.0 0.0%
Modify
●
●
●
●
●
●
●
●
●
●
●
●
●
●
●
●
●
●
●
●
●
●
