INVT Goodrive3000 Series Operation Manual page 50

Goodrive3000 series medium voltage VFD
Function
Name
code
IGBT temperature at
P10.13
present fault
Record the IGBT temperature when fault occurs and display 3PH IGBT temperature at no fault.
Function
Name
code
Input terminal state
P10.22
at last fault
Output terminal state
P10.23
at last fault
DC bus voltage at
P10.24
last fault
Grid voltage at last
P10.25
fault
Input current at last
P10.26
fault
IGBT temperature at
P10.29
last fault
Record the IGBT temperature when fault occurs and display 3PH IGBT temperature at no fault.
Record the parameters at last fault. For details, refer to P10.22–P10.29.
Function
Name
code
Input terminal state
P10.38
at 2nd-last fault
Output terminal state
P10.39
at 2nd-last fault
DC bus voltage at
P10.40
2nd-last fault
Grid voltage at
P10.41
2nd-last fault
Input current at
P10.42
2nd-last fault
Description
-20.0–120.0° C
Description
0x0–0xF
0x0–0xF
0.0–6000.0V
0.0–4000.0V
0.0–6000.0A
-20.0–120.0° C
Description
0x0–0xF
0x0–0xF
0.0–6000.0V
0.0–4000.0V
0.0–6000.0A
-45-
Goodrive3000 PWM rectifier
Setting range
-20.0–120.0° C
Setting range
0x0–0xF
0x0–0xF
0.0–6000.0V
0.0–4000.0V
0.0–6000.0A
-20.0–120.0° C
Setting range
0x0–0xF
0x0–0xF
0.0–6000.0V
0.0–4000.0V
0.0–6000.0A
Default
0.0° C
Default
0x0
0x0
0.0V
0.0V
0.0A
0.0° C
Default
0x0
0x0
0.0V
0.0V
0.0A
