code
running frequency
The lower limit of running frequency is the lower limit of output frequency of the VFD.
If the set frequency is lower than the lower limit, the VFD runs at the lower limit.
Note: Max. output frequency ≥ Upper limit frequency ≥ Lower limit frequency
Function
Name
code
A frequency
P00.06
command
B frequency
P00.07
command
0: Keypad data setting
Modify the value P00.10 (set frequency by keypad) to set the frequency by keypad.
1: AI1 setting
2: AI2 setting
3: AI3 setting
Set the frequency by analog input terminals. The VFD provides 2 channel analog input terminals, among
which AI1/AI3 is the voltage/current option (0–10V/0–20mA) and can be shifted by jumpers while AI2 is
the voltage input (-10V–+10V).
Note: When the analog AI1/AI3 selects 0–20mA input, the corresponding voltage of 20mA is 10V.
100.0% of the analog input setting corresponds to Max. output frequency (P00.03) and -100.0%
corresponds to the max output frequency (P00.03).
4: HDI setting
The frequency is set by the high-speed pulse terminals. The VFD provides 1 channel high-speed pulse
input in the range of 0.00–50.00kHz.
100.0% of the high-speed pulse input setting corresponds to Max. output frequency (P00.03) in forward
Description
running frequency)
Description
0: Keypad data setting
1: AI1 setting
2: AI2 setting
3: AI3 setting
4: HDI setting
5: Simple PLC program setting
6: Multi-step speed running setting
7: PID control setting
8: MODBUS communication setting
9: PROFIBUS/CANopen
communication setting
10: Ethernet communication setting
11: Reserved
-79-
Goodrive3000 inverter
Setting range Default
Setting range Default
0–11 0
0–11 1
