INVT Goodrive3000 Series Operation Manual page 226

Goodrive3000 series medium voltage VFD
Function
Name
code
detection value
FDT2 electrical
P08.34 level detection
value
FDT2 retention
P08.35
detection value
Frequency arrival
P08.36
detection value
Energy braking
P08.37
enable
Threshold
P08.38 voltage of energy
braking
Running mode of
P08.39
cooling fan
P08.40 Reserved
Over modulation
P08.41
selection
Keypad data
P08.42
control
Description
0.00–P00.03 (Max. frequency)
0.0–100.0% (FDT2 electrical level)
0.0–P00.03 (Max. frequency)
0: Disabled
1: Enabled
600.0–6000.0V
0: Normal running mode
1: The fan keeps running after power on
all the time.
0: Invalid
1: Valid
0x0000–0x1223
LED ones: Frequency enabling
selection
0: Both ∧/∨ and digital potentiometer
adjustments are effective.
1: Only ∧/∨ is effective.
2: Only digital potentiometer adjustment
is effective.
3: Neither ∧/∨ nor digital
potentiometer adjustments is effective.
LED tens: Frequency control selection
0: Only effective when P00.06=0 or
P00.07=0
1: Effective for all frequency setting
manners
2: Ineffective for multi-step speed when
-221-
Goodrive3000 inverter
Setting range Default
0.00–P00.03 50.00Hz
0.0–100.0 5.0%
0.0–P00.03 0.00Hz
0–1 0
600.0–6000.0 1950.0V
0–1 0
0–1 1
0000–1223 0x0000
Modify
○
○
○
○
○
○
◎
◎
○
