Goodrive3000 series medium voltage VFD
Function
Name
code
P20.02 Encoder direction
Encoder offline
P20.03
detection time
Encoder reverse
P20.04
detection time
Encoder
P20.05 detection filter
times
Speed ratio
P20.06 between motor
and encoder
P20.07 Reserved
P20.08 Reserved
P20.09 Reserved
Magnetic pole
P20.10
initial angle
Magnetic pole
P20.11 initial angle
autotuning
Reserved
P20.12
variable
Reserved
P20.13
variable
Reserved
P20.14
variable
P21 group––Master-slave control
Description
LED ones: AB direction
0: Forward
1: Reverse
LED tens: Z pulse direction
0: Forward
1: Reverse
0.0–100.0s
0.0–100.0s
Ones: Low-speed filter times
Tens: High-speed filter times
0.000–65.535
0.00–359.99
0–2
0: No operation
1: Rotation autotuning
2: Static autotuning (suitable for rotary
encoder feedback)
0–65535
0–65535
0–65535
-241-
Goodrive3000 inverter
Setting range Default
0–0x11 0x00
0–100.0 0.5s
0–100.0 0.8s
0–0x99 0x23
0.000–65.535 1.000
0.00–359.99 0
0–2 0
0–65535 0
0–65535 0
0–65535 0
Modify
◎
○
○
○
○
○
○
○
○
◎
○
○
○
