INVT Goodrive3000 Series Operation Manual page 201

Goodrive3000 series medium voltage VFD
Function
Name
code
P02.25 Reserved
Motor 1 overload
P02.26
protection
Motor 1 overload
P02.27 protection
coefficient
Motor 1 power
P02.28 correction
coefficient
Motor 1
P02.29 parameter
display
P03 group––Vector control
Speed loop
P03.00 proportional gain
1
Speed loop
P03.01
integral time 1
Switching low
P03.02
frequency
Speed loop
P03.03 proportional gain
2
Speed loop
P03.04
integral time 2
Switching high
P03.05
frequency
Speed loop
P03.06
output filter
Vector control
slip
P03.07
compensation
coefficient
Description
0: No protection
1: Common motor (with low speed
compensation)
2: Frequency conversion motor (without
low speed compensation)
20.0%–120.0%
0.00–3.00
0: Display according to motor type
1: Display all parameters
0–200.0
0.000–10.000s
0.00Hz–P03.05
0–200.0
0.001–10.000s
P03.02–P00.03(Max. frequency)
0–8 (corresponding to 0–2^8/10ms)
50–200%
-196-
Goodrive3000 inverter
Setting range Default
0–2 2
20.0–120.0 100.0%
0.00–3.00 1.00
0–1 0
0–200.0 20.0
0.000–10.000 1.000s
0.00–P03.05 5.00Hz
0–200.0 20.0
0.000–10.000 1.000s
P03.02–P00.03 10.00Hz
0–8 0
50–200 100%
Modify
●
◎
○
○
○
○
○
○
○
○
○
○
○
