Goodrive3000 series medium voltage VFD
Setting value
1
2
3
4
5
6–12
13
consumption cleared
Accumulative power
14
15
Function
Name
code
P05.12 Delay time of S1
switching-on
P05.13 Delay time of S1
switching-off
P05.14 Delay time of S2
switching-on
P05.15 Delay time of S2
switching-off
P05.16 Delay time of S3
switching-on
P05.17 Delay time of S3
switching-off
P05.18 Delay time of S4
switching-on
P05.19 Delay time of S4
switching-off
Function
misaction.
Run Control the operation through external terminals.
External fault reset, same as the function of STOP/RST.
Fault reset
Remote fault reset is available by the function.
PWM rectifier reports fault and stops when external fault
External fault signal is sent to the rectifier. The main contactor does
not switch off and the diode rectifier works normally.
Reserved
Run enabling PWM rectifier works after the enabling terminal is valid.
Reserved
Total electricity Total electricity consumption is cleared if the command
is valid (P07.17 and P07.18).
The current operation does not affect the accumulative
maintain power if the command is valid.
Reserved
Description
The function codes are used to set
the delay time when electric level
changes.
Goodrive3000 PWM rectifier
Description
