Goodrive3000 series medium voltage VFD
Function
Name
code
P17.11 DC bus voltage
Digital input
P17.12
terminals state
Digital output
P17.13
terminals state
P17.14 Digital adjustment
P17.15 Torque reference
P17.19 AI1 input voltage
P17.20 AI2 input voltage
P17.21 AI3 input voltage
P17.22 HDI input frequency
P17.23 PID reference
P17.24 PID feedback
Power factor of the
P17.25
motor
P17.26 Current running time Display the current running time of
Description
Display current DC bus voltage of
the VFD
Range: 0.0–6000.0V
Display current switch input
terminals state of the VFD
0000–00FF
Display current switch output
terminals state of the VFD
0000–000F
Display the adjustment through the
keypad of the VFD.
Range : 0.00Hz–P00.03
Display the torque given, the
percentage to the current rated
torque of the motor.
Setting range: -300.0%–300.0%
(the rated current of the motor)
Display analog AI1 input signal
Range: 0.00–10.00V
Display analog AI2 input signal
Range: -10.00–10.00V
Display analog AI3 input signal
Range: 0.00–10.00V
Display HDI input frequency
Range: 0.00–50.00kHz
Display PID given value
Range: -100.0–100.0%
Display PID response value
Range: -100.0–100.0%
Display the current power factor of
the motor.
Range: -1.00–1.00
-172-
Goodrive3000 inverter
Setting range Default
0.0–6000.0 0V
0000–00FF 0
0000–000F 0
0.00Hz–P00.03 0.00Hz
-300.0–300.0 0.0%
0.00–10.00 0.00V
-10.00–10.00 0.00V
0.00–10.00 0.00V
0.00–50.00 0.00 kHz
-100.0–100.0 0.0%
-100.0–100.0 0.0%
-1.00–1.00 0.0
0–65535 0min
