The second to twelfth words in a PZD task packet are the main actual values. The main actual frequency
values are provided by the main actual value signal source.
Word
Sent PZD2 0: Invalid
1: DC voltage (*10, V)
Sent PZD3
2: DC voltage feedback (*10, V)
Sent PZD4
3: Valid value of input voltage (*10, V)
Sent PZD5
4: Valid value of input current (*10, A)
5: Input power (*10, kW)
Sent PZD6
6: Input power factor (*100)
Sent PZD7
7: Grid frequency value (*10, Hz)
Sent PZD8
8: Active current feedback (100% corresponds to the
rectifier rated current)
Sent PZD9
9: Reactive current feedback(100% corresponds to
Sent PZD10
the rectifier rated current)
10: Fault code
Sent PZD11
11: AI1 value (*100, V)
12: AI2 value (*100, V)
13: Reserved
14: Terminal input state
Sent PZD12
15: Terminal output state
16: Running status word
17–20: Reserved
Word
PZD2
PZD3
PZD4
PZD5
PZD6
PZD7
Table 9.11 Rectifier actual values
Value range
Table 9.12 VFD actual value
Name
Fault code
Speed feedback
PG card position
Drive torque feedback
Motor running frequency feedback
Drive current feedback
-286-
PROFIBUS communication
Function selection
0
0
0
0
0
0
0
0
0
0
0
Value sent from slave to master
Fault code, 0–N.
Actual value of speed.
PG card position.
Actual value of torque.
Actual value of motor running
frequency.
Actual value of drive current.
