P14 Group--Serial Communication - INVT Goodrive3000 Series Operation Manual

Goodrive3000 series medium voltage VFD
P14 group––Serial communication
Function
Name
code
Local communication
P14.00
address
When the master is at write frame and the communication address of the slave is set to 0 (broadcast
communication address), all the slaves of the MODBUS will accept the frame without response.
Local communication address is unique in communication network and it is the foundation to achieve
point-to-point communication between the upper computer and VFD.
Note: The address of the slave cannot be set to 0.
Function
Name
code
Communication
P14.01
baud rate
Set the data baud rate between the upper computer and VFD.
Note: The baud rates set by the upper computer and VFD should agree with each other; otherwise, the
communication is disabled. The larger the baud rate is, the faster the communication is.
Function
Name
code
P14.02 Data bit checkout
The data formats set by the upper computer and VFD should agree with each other; otherwise, the
communication is disabled.
Description
1–247
0 is broadcast communication
address.
Description
0: 1200BPS
1: 2400BPS
2: 4800BPS
3: 9600BPS
4: 19200BPS
5: 38400BPS
6: 57600BPS
Description
0: No check (N, 8, 1) for RTU
1: Even check (E, 8, 1) for RTU
2: Odd check (O, 8, 1) for RTU
3: No check (N, 8, 2) for RTU
4: Even check (E, 8, 2) for RTU
5: Odd check (O, 8, 2) for RTU
-162-
Goodrive3000 inverter
Setting range Default
1–247 1
Setting range Default
0–6 4
Setting range Default
0–5 1
