Goodrive3000 series medium voltage VFD
Function
Name
code
HDO
P06.09 switching-on
delay time
HDO
P06.10 switching-off
delay time
Relay RO1
P06.11 switching-on
delay time
Relay RO1
P06.12 switching-off
delay time
Relay RO2
P06.13 switching-on
delay time
Relay RO2
P06.14 switching-off
delay time
Relay RO3
P06.15 switching-on
delay time
Relay RO3
P06.16 switching-off
delay time
P06.17 AO1 output
P06.18 AO2 output
P06.19 AO3 output
HDO pulse
P06.20
output
Description
0.000–50.000s (only valid when
P06.00=1)
0.000–50.000s (only valid when
P06.00=1)
0.000–50.000s
0.000–50.000s
0.000–50.000s
0.000–50.000s
0.000–50.000s
0.000–50.000s
0: Running frequency
1: Set frequency
2: Ramp reference frequency
3: Running rotating speed
4: Output current (Relative to VFD)
5: Output current (Relative to motor)
6: Output voltage
7: Output power
8: Set torque value
9: Output torque
10: AI1 input value
11: AI2 input value
-209-
Goodrive3000 inverter
Setting range Default
0.000–50.000 0.000s
0.000–50.000 0.000s
0.000–50.000 0.000s
0.000–50.000 0.000s
0.00–50.00 0.000s
0.00–50.00 0.000s
0.00–50.00 0.000s
0.00–50.00 0.000s
0–30 0
0–30 0
0–30 0
0–30 0
Modify
○
○
○
○
○
○
○
○
○
○
○
