Goodrive3000 series medium voltage VFD
Function
Name
code
The parameters are used to set the corresponding functions of digital multi-functional input terminals.
Note: Two different multi-functional input terminals cannot be set to the same function.
Set value Function
0 No function
Forward rotation
1
operation (FWD)
Reverse rotation
2
operation (REV)
3
3-wire control
Description
23: Simple PLC stop reset
24: Simple PLC pause
25: PID control pause
26: Reserved
27: Reserved
28: Reserved
29: Torque control prohibition
30: ACC/DEC prohibition
31: Reserved
32: Reserved
33: Cancel the frequency change
setting temporarily
34: DC brake
35: Shift motor 1 to motor 2
36: Shift the command to the keypad
37: Shift the command to the
terminals
38: Shift the command to the
communication
39: Pre-exciting command
40: Consumption power clear
41: Consumption power holding
42: External fault input 2
43–63: Reserved
The VFD will not work even when there are signals to input. The
terminals out of use may be set with no function in case of
malfunction.
Both the forward rotation and reverse rotation of the VFD are
controlled by external terminals.
The terminal is used to ensure the running mode of the VFD is
-107-
Goodrive3000 inverter
Setting range
Instruction
Default
