9.6 Related function codes

Rectifier related function codes
Function
Name
code
P12.00 Module type
P12.01 Module address
P12.02 Received PZD2
P12.03 Received PZD3
P12.04 Received PZD4
P12.05 Received PZD5
P12.06 Received PZD6
P12.07 Received PZD7
P12.08 Received PZD8
P12.09 Received PZD9
P12.10 Received PZD10
P12.11 Received PZD11
P12.12 Received PZD12
P12.13 Sent PZD2
P12.14 Sent PZD3
P12.15 Sent PZD4
P12.16 Sent PZD5
P12.17 Sent PZD6
P12.18 Sent PZD7
P12.19 Sent PZD8
P12.20 Sent PZD9
P12.21 Sent PZD10
P12.22 Sent PZD11
P12.23 Sent PZD12
Description
0: Profibus
0–127
0: Invalid
1: DC voltage setting (0–40000; unit:
0.1V)
2–4: Reserved
5: AO setting (1-1000–1000, 1000
corresponding to 100.0%)
6: AO setting 2 (1-1000–1000, 1000
corresponding to 100.0%)
7–13: Reserved
0: Invalid
1: DC voltage (*10, V)
2: DC voltage feedback (*10, V)
3: Valid value of input voltage (*10, V)
4: Valid value of input current (*10, A)
5: Input power (*10, kW)
6: Input power factor (*100)
7: Grid frequency value (*10, Hz)
8: Active current feedback (100%
corresponds to the rectifier rated
current)
9: Reactive current feedback (100%
corresponds to the rectifier rated
current)
10: Fault code
11: AI1 value (*100, V)
-289-
PROFIBUS communication
Setting Defau
range lt
0 0
0–127 2
0–13 0
0–13 0
0–13 0
0–13 0
0–13 0
0–13 0
0–13 0
0–13 0
0–13 0
0–13 0
0–13 0
0–20 0
0–20 0
0–20 0
0–20 0
0–20 0
0–20 0
0–20 0
0–20 0
0–20 0
0–20 0
0
0–20
