INVT Goodrive3000 Series Operation Manual page 67

Goodrive3000 series medium voltage VFD
Function
Name
code
S2 terminal function
P05.05
selection
S3 terminal function
P05.06
selection
S4 terminal function
P05.07
selection
P05.08 Reserved
P05.09 Reserved
P05.10 Reserved
P05.11 Reserved
Delay time of S1
P05.12
switching-on
Delay time of S1
P05.13
switching-off
Delay time of S2
P05.14
switching-on
Delay time of S2
P05.15
switching-off
Delay time of S3
P05.16
switching-on
Delay time of S3
P05.17
switching-off
Delay time of S4
P05.18
switching-on
Delay time of S4
P05.19
switching-off
P05.20 Reserved
P05.21 Reserved
P05.22 Reserved
P05.23 Reserved
P05.24 Reserved
Description
1: Run
2: Fault reset
3: External fault
4: Reserved
5: Run enabling
6: Reserved
7–12: Reserved
13: Total electricity
consumption cleared
14: Accumulative power
maintain
15: Reserved
0.000–60.000s
0.000–60.000s
0.000–60.000s
0.000–60.000s
0.000–60.000s
0.000–60.000s
0.000–60.000s
0.000–60.000s
-62-
Goodrive3000 PWM rectifier
Setting
Default
range
2
0
0
0
0
0
0
0.000–60.000 0.000s
0.000–60.000 0.000s
0.000–60.000 0.000s
0.000–60.000 0.000s
0.000–60.000 0.000s
0.000–60.000 0.000s
0.000–60.000 0.000s
0.000–60.000 0.000s
