Function Name
4 Output voltage
5 Output current
Output torque actual
6
value
Output power actual
7
value
Running rotating
8
speed
9 Running linear speed (*1, m/s)
Ramp reference
10
frequency
11 fault code
12 AI1 value
13 AI2 value
14 AI3 value
15 PULSE frequency
Input state of
16
terminals
Output state of
17
terminals
18 PID reference
19 PID feedback
20 Motor rated torque
Function
Name
code
Temporary variable 1
P15.24
for PZD sending
The function code is use as the temporary variable when PZD sends data.
The function code P15.24 is enabled to write at any state.
(*1, V)
(*10, A)
(*10, %)
(*10, %)
(*1, RPM)
(*100, V)
(*100, V)
(*100, V)
(*100, kHz)
(*100, %)
(*100, %)
Description
0–65535
-168-
Goodrive3000 inverter
Illustration
Setting range
0–65535
Default
0
