INVT Goodrive3000 Series Operation Manual page 126

Goodrive3000 series medium voltage VFD
Function
Name
code
Y switching-on delay
P06.07
time
Y switching-off delay
P06.08
time
HDO switching-on
P06.09
delay time
HDO switching-off
P06.10
delay time
Relay RO1
P06.11 switching-on delay
time
Relay RO1
P06.12 switching-off delay
time
Relay RO2
P06.13 switching-on delay
time
Relay RO2
P06.14 switching-off delay
time
Relay RO3
P06.15 switching-on delay
time
Relay RO3
P06.16 switching-off delay
time
The function code defines the corresponding delay time of the electrical level variation of programmable
output terminals from switching-on to switching-off.
Function
Name
code
P06.17 AO1 output
P06.18 AO2 output
Description
0.000–50.000s
0.000–50.000s
0.000–50.000s (only valid when
P06.00=1)
0.000–50.000s (only valid when
P06.00=1)
0.000–50.000s
0.000–50.000s
0.000–50.000s
0.000–50.000s
0.000–50.000s
0.000–50.000s
Y electric level
Invalid
Y valid
Switch on
delay
Description
0: Running frequency
1: Set frequency
-121-
Goodrive3000 inverter
Setting range
0.000–50.000
0.000–50.000
0.000–50.000
0.000–50.000
0.000–50.000
0.000–50.000
0.000–50.000
0.000–50.000
0.00–50.00
0.00–50.00
invalid
Valid
Switch off
delay
Setting range
0–30
0–30
Default
0.000s
0.000s
0.000s
0.000s
0.000s
0.000s
0.000s
0.000s
0.000s
0.000s
Default
0
0
