INVT Goodrive3000 Series Operation Manual page 212

Goodrive3000 series medium voltage VFD
Function
Name
code
Middle value of
P05.46
AI3
Corresponding
P05.47 setting of AI3
middle value
P05.48 AI3 upper limit
Corresponding
P05.49 setting of AI3
upper limit
AI3 input filter
P05.50
time
HDI pulse input
P05.51
function
HDI lower-limit
P05.52
frequency
Corresponding
setting of HDI
P05.53
lower-limit
frequency
HDI upper-limit
P05.54
frequency
Corresponding
setting of HDI
P05.55
upper-limit
frequency
Input filter time of
P05.56 HDI pulse
frequency
P06 group––Output terminals
P06.00 HDO output type
Y1 output
P06.01
P06.02 HDO output
Description
P05.44–P05.48
-100.0%–100.0%
P05.46–10.00V
-100.0%–100.0%
0.000s–10.000s
0: Frequency setting input
1–2: Reserved
0.00kHz–P05.54
-100.0%–100.0%
P05.52–50.00kHz
-100.0%–100.0%
0.000s–10.000s
0: Open collector output
1: Reserved
0: Invalid
1: In operation
2: Forward rotation operation
-207-
Goodrive3000 inverter
Setting range Default
P05.44–P05.48 0.00V
-100.0–100.0 0.0%
P05.46–10.00 10.00V
-100.0–100.0 100.0%
0.000–10.000 0.100s
0–2 0
0.00–P05.54 0.00KHz
-100.0–100.0 0.0%
P05.52–50.00 50.00KHz
-100.0–100.0 100.0%
0.000–10.000 0.100s
0–1 0
0–30 0
0–30 0
Modify
○
○
○
○
○
◎
○
○
○
○
○
◎
○
○
