Goodrive3000 series medium voltage VFD
Function
Name
code
Automatic current
P11.06
limit level
Frequency
decreasing
P11.07
velocity during
current limit
VFD/Motor
underload and
P11.08
overload
pre-alarm
Detection level of
P11.09 overload
pre-alarm
Detection time of
P11.10 overload
pre-alarm
Detection level of
P11.11 underload
pre-alarm
Detection time of
P11.12
underload
Description
50.0–200.0% (100% corresponds to
rated current)
0.00–50.00Hz/s
0x000–0x131
LED ones:
0: Motor underload and overload
pre-alarm, relative to motor rated
current
1: VFD underload and overload
pre-alarm, relative to VFD rated current
LED tens:
0: VFD continues running after
underload and overload pre-alarm
1: VFD continues running after
underload pre-alarm and stop running
after overload fault
2: VFD continues running after overload
pre-alarm and stop running after
underload fault
3: VFD stops running after underload
and overload alarm
LED hundreds:
0: Detect all the time
1: Detect in constant running
P11.11–200%
0.1–60.0s
0%–P11.09
0.1–60.0s
-229-
Goodrive3000 inverter
Setting range Default
G型机:
50.0–200.0
160.0%
0.00–50.00 10.00Hz/s
000–131 0x000
P11.11–200 150%
0.1–60.0 1.0s
0–P11.09 50%
0.1–60.0 1.0s
Modify
◎
◎
○
○
○
○
○
