Goodrive3000 series medium voltage VFD
P17 group––State view 1
Function
Name
code
P17.00 Setting frequency
P17.01 Output frequency
Ramp reference
P17.02
frequency
P17.03 Output voltage
P17.04 Output current
P17.05 Motor speed
P17.06 Torque current
P17.07 Exciting current
P17.08 Motor power
P17.09 Output torque
Evaluated motor
P17.10
frequency
Description
Display current set frequency of the
VFD
Range: 0.00Hz–P00.03
Display current output frequency of
the VFD
Range: 0.00Hz–P00.03
Display current ramp given
frequency of the VFD
Range: 0.00Hz–P00.03
Display current output voltage of the
VFD
Range: 0–4000V
Display current output current of the
VFD
Range: 0.0–3000.0A
Display the rotation speed of the
motor.
Range: 0–65535RPM
Display current torque current of the
VFD
Range: -3000.0–3000.0A
Display current exciting current of
the VFD
Range: -3000.0–3000.0A
Display current power of the motor.
Setting range: -300.0%–300.0%
(the rated current of the motor)
Display the current output torque of
the VFD.
Range: -250.0–250.0%
Evaluate the motor rotor frequency
on open loop vector
Range: 0.00– P00.03
-171-
Goodrive3000 inverter
Setting range Default
0.00–P00.03 0.00Hz
0.00–P00.03 0.00Hz
0.00–P00.03 0.00Hz
0–4000 0V
0.0–3000.0 0.0A
0–65535 0 RPM
-3000.0–3000.0A 0.0A
-3000.0–3000.0A 0.0A
-300.0–300.0 0.0%
-250.0–250.0 0.0%
0.00–P00.03 0.00Hz
