Goodrive3000 series medium voltage VFD
Function
Name
code
source selection
Note: 100% of the setting methods 1–9 corresponds to the maximum frequency.
Note: 3, 4, 7 and 8 need to use extension cards.
Function
Name
code
Keypad defined
value of torque
P03.16 control forward
rotation upper-limit
frequency
Keypad defined
value of torque
P03.17 control reverse
rotation upper-limit
frequency
The function code is used to set upper limit of the frequency, 100% corresponding to the maximum
frequency. P03.16 sets P03.14 and P03.17 sets P03.15.
Function
Name
code
Electromotion
P03.18 torque upper-limit
setting source
Braking torque
P03.19 upper-limit setting
source
The function code is used to select electromotion and braking torque upper-limit setting source.
Description
7: PROFIBUS/CANopen
communication setting
8: Ethernet communication setting
9: Reserved
Description
0.00Hz–P00.03
0.00Hz–P00.03
Description
0: Keypad setting (P03.20 sets
P03.18 and P03.21 sets P03.19)
1: AI1 setting
2: AI2 setting
3: AI3 setting
4: HDI pulse frequency setting
5: MODBUS communication setting
6: PROFIBUS/CANopen
communication setting
7: Ethernet communication setting
8: Reserved
-97-
Goodrive3000 inverter
Setting range Default
Setting range Default
0.00–P00.03 50.00Hz
0.00–P00.03 50.00Hz
Setting range Default
0–8 0
0–8 0
