INVT Goodrive3000 Series Operation Manual page 203

Goodrive3000 series medium voltage VFD
Function
Name
code
frequency setting
source selection
Keypad defined
value of torque
control forward
P03.16
rotation
upper-limit
frequency
Keypad defined
value of torque
control reverse
P03.17
rotation
upper-limit
frequency
Electromotion
P03.18 torque upper-limit
setting source
Braking torque
P03.19 upper-limit
setting source
Electromotion
P03.20 torque upper-limit
keypad setting
Braking torque
P03.21 upper-limit
keypad setting
Weakening
coefficient in
P03.22
constant power
field
Description
6: MODBUS communication setting
7: PROFIBUS/CANopen
communication setting
8: Ethernet communication setting
9: Reserved
0.00Hz–P00.03
0.00Hz–P00.03
0: Keypad setting (P03.20 sets P03.18
and P03.21 sets P03.19)
1: AI1 setting
2: AI2 setting
3: AI3 setting
4: HDI pulse frequency setting
5: MODBUS communication setting
6: PROFIBUS/CANopen
communication setting
7: Ethernet communication setting
8: Reserved
0.0–300.0% (Motor rated current)
0.0–300.0% (Motor rated current)
0.1–2.0
-198-
Goodrive3000 inverter
Setting range Default
0.00–P00.03 50.00 Hz
0.00–P00.03 50.00Hz
0–8 0
0–8 0
0.0–300.0 180.0%
0.0–300.0 180.0%
0.1–2.0 0.3
Modify
○
○
○
○
○
○
○
