INVT Goodrive3000 Series Operation Manual page 110

Goodrive3000 series medium voltage VFD
Function
Name
code
Keypad setting
P04.28
voltage
The function code is the voltage digital set value when the voltage setting channel is selected as "keypad
setting" (P04.27=0).
Function
Name
code
Voltage increasing
P04.29
time
Voltage decreasing
P04.30
time
Voltage increasing time is the time required by the VFD which accelerates from 0V to the rated voltage.
Voltage decreasing time is the time required by the VFD which decelerates from the rated voltage to 0V.
Function
Name
code
P04.31 Max. output voltage
P04.32 Min output voltage
Set the upper and lower limit of the output voltage.
Description
0.0%–100.0% (Motor rated voltage)
Description
0.0–3600.0s
0.0–3600.0s
Description
P04.32–100.0% (Motor rated
voltage)
0.0%–P04.31 (Motor rated voltage)
Vmax
V set
Vmin
t1
-105-
Goodrive3000 inverter
Setting range
0.0–100.0
Setting range
0.0–3600.0
0.0–3600.0
Setting range
P04.32–100.0
0.0–P04.31
t1=P04.29
t2=P04.30
t2
Time t
Default
100.0%
Default
5.0s
5.0s
Default
100.0%
0.0%
