Goodrive3000 series medium voltage VFD
Function
Name
code
Motor 1 V/F
P04.06
voltage point 2
Motor 1 V/F
P04.07
frequency point 3
Motor 1 V/F
P04.08
voltage point 3
Motor 1 V/F slip
P04.09 compensation
gain
Motor 1 low
frequency
P04.10
oscillation control
factor
Motor 1 high
frequency
P04.11
oscillation control
factor
Motor 1
P04.12 oscillation control
threshold
Motor 2 V/F
P04.13
curve setting
Motor 2 V/F
P04.14
torque boost
Motor 2 V/F
P04.15 torque boost
close
Description
0.0%–110.0% (Rated voltage of motor
1)
P04.05–P02.02 (Rated frequency of
motor 1)/ P04.05–P02.16 (Rated
frequency of motor 1)
0.0%–110.0% (Rated voltage of motor
1)
0.0–200.0%
0–100
0–100
0.00Hz–P00.03 (Max. frequency)
0: Straight line V/F curve
1: Multi-dot V/F curve
2: Torque step-down V/F curve (power
of 1.3)
3: Torque step-down V/F curve (power
of 1.7)
4: Torque step-down V/F curve (power
of 2.0)
5: Customized V/F curve (V/F
separation)
0.0%: (Automatic) 0.1%–10.0%
0.0%–50.0% (Relative to rated
frequency of motor 2)
-200-
Goodrive3000 inverter
Setting range Default
0.0–110.0 00.0%
P04.05–Rated
frequency of 00.00Hz
motor 1
0.0–110.0 00.0%
0.0–200.0 100.0%
0–100 10
0–100 10
0.00Hz–P00.03 30.00 Hz
0–5 0
0.0–10.0 0.0%
0.0–50.0 20.0%
Modify
○
○
○
○
○
○
○
◎
○
○
