INVT Goodrive3000 Series Operation Manual page 236

Goodrive3000 series medium voltage VFD
Function
Name
code
Asynchronous
P12.06 motor 2 stator
resistor
Asynchronous
P12.07 motor 2 rotor
resistor
Asynchronous
P12.08 motor 2 leakage
inductance
Asynchronous
P12.09 motor 2 mutual
inductance
Asynchronous
P12.10 motor 2 non-load
current
Magnetic
saturation
P12.11 coefficient 1 for
the iron core of
AM 2
Magnetic
saturation
P12.12 coefficient 2 for
the iron core of
AM 2
Magnetic
saturation
P12.13 coefficient 3 for
the iron core of
AM 2
Magnetic
saturation
P12.14 coefficient 4 for
the iron core of
AM 2
P12.15 Reserved
P12.16 Reserved
P12.17 Reserved
Description
0.001–65.535Ω
0.001–65.535Ω
0.1–6553.5mH
0.1–6553.5mH
0.1–6553.5A
0.0–100.0%
0.0–100.0%
0.0–100.0%
0.0–100.0%
-231-
Goodrive3000 inverter
Setting range Default
Depends
0.001–65.535
on model
Depends
0.001–65.535
on model
Depends
0.1–6553.5
on model
Depends
0.1–6553.5
on model
Depends
0.1–6553.5
on model
0.0–100.0 80.0%
0.0–100.0 68.0%
0.0–100.0 57.0%
0.0–100.0 40.0%
Modify
○
○
○
○
○
◎
◎
◎
◎
◎
◎
◎
