INVT Goodrive3000 Series Operation Manual page 146

Goodrive3000 series medium voltage VFD
Function
Name
code
Set the control functions of the keypad.
Function
Name
code
Integral ratio of the
P08.43 keypad
potentiometer
UP/DOWN terminal
P08.44
control
Description
effective.
LED tens: Frequency control
selection
0: Only effective when P00.06=0 or
P00.07=0
1: Effective for all frequency setting
manners
2: Ineffective for multi-step speed
when multi-step speed has the
priority
LED hundreds: Action selection
during stopping
0: Effective setting
1: Effective during running, cleared
after stopping
2: Effective during running, cleared
after receiving the stop command
LED thousands: ∧/∨ and digital
potentiometer integral function
0: Effective integral function
1: Ineffective integral function
Description
0.01–10.00s
0x000–0x221
LED ones: Frequency control
selection
0: UP/DOWN terminal setting
effective
1: UP/DOWN terminal setting
ineffective
LED tens: Frequency control
selection
0: Only effective when P00.06=0 or
-141-
Goodrive3000 inverter
Setting range Default
Setting range Default
0.01–10.00 0.10s
000–221 0x000
