Goodrive3000 series medium voltage VFD
Function
Name
code
LED ones:
0: Keep the integral adjustment when the frequency reaches the upper and lower limit: the integration
responses the changes between the reference and feedback unless it reaches the internal integral limit.
When the size between the reference and feedback changes, it needs more time to offset the impact of
continuous working integration and the integration can change with the trend.
1: Stop the integral adjustment when the frequency reaches the upper and lower limit: if the integration
keeps stable and the size between the reference and feedback changes, the integration will change
along with the trend quickly.
Function
Name
code
Proportional gain at
P09.14
low frequency (Kp)
PID command of
P09.15
ACC/DEC time
P09.16 PID output filter time 0.000–10.000s
Description
0: Limit to the maximum frequency
1: Limit to frequency A
LED thousands:
0:A+B frequency, the buffer of A
frequency is invalid
1:A+B frequency, the buffer of A
frequency is valid
ACC/DEC is determined by ACC
time 4 of P08.04
Description
0.00–100.00
0.0–1000.0s
-149-
Goodrive3000 inverter
Setting range Default
Setting range Default
0.00–100.00 1.00
0.0–1000.0s 0.0s
0.000–10.000s 0.000s
