INVT Goodrive3000 Series Operation Manual page 135

Goodrive3000 series medium voltage VFD
Function
Name
code
The parameter at
P07.07
stop state
The setting way of P07.07 is the same with that of P07.06. When Goodrive3000 series VFDs are at stop
state, the parameter display is influenced by P7.07.
BIT15 BIT14
Reserved Reserved
BIT7 BIT6
Torque set
AI1 value
value
Function
Name
code
Frequency
P07.08
coefficient
Rotating speed
P07.09
coefficient
Description
BIT0: Set frequency (Hz on,
frequency flickering slowly)
BIT1: Bus voltage (V on)
BIT2: Input terminal state
BIT3: Output terminal state
BIT4: PID reference (% flickering)
BIT5: PID feedback (% on)
BIT6: Torque set value (% on)
BIT7: AI1 value (V on)
BIT8: AI2 value (V on)
BIT9: AI3 value (V on)
BIT10: HDI frequency
BIT11: PLC and current step in
multi-step speed
BIT12: Reserved
BIT13: Reserved
BIT14–BIT15: Reserved
BIT13 BIT12
Reserved Reserved
BIT5 BIT4
PID PID
feedback reference
Description
0.01–10.00
0.1–999.9%
-130-
Setting range
0x0000–0xFFFF
BIT11 BIT10
PLC and
current step HDI
in multi-step frequency
speed
BIT3 BIT2
Output Input
terminal terminal
state state
Setting range
0.01–10.00
0.1–999.9
Goodrive3000 inverter
Default
0x00FF
BIT9 BIT8
AI3 value AI2 value
BIT1 BIT0
Bus Set
voltage frequency
Default
1.00
100.0%
