INVT Goodrive3000 Series Operation Manual page 120

Goodrive3000 series medium voltage VFD
Si Electrical
Function
Name
code
P05.32 AI1 lower limit
Corresponding
P05.33 setting of AI1 lower
limit
P05.34 AI1 upper limit
Corresponding
P05.35 setting of AI1 upper
limit
P05.36 AI1 input filter time
P05.37 AI2 lower limit
Corresponding
P05.38 setting of AI2 lower
limit
P05.39 AI2 middle value
Corresponding
P05.40 setting of AI2 middle
value
P05.41 AI2 upper limit
Corresponding
P05.42 setting of AI2 upper
limit
P05.43 AI2 input filter time
P05.44 AI3 lower limit
Corresponding
P05.45 setting of AI3 lower
limit
P05.46 Middle value of AI3 P05.44–P05.48
level
Invalid
Si Valid
Switch-on delay
0.00V–P05.34
-100.0%–100.0%
P05.32–10.00V
-100.0%–100.0%
0.000s–10.000s
-10.00V–P05.39
-100.0%–100.0%
P05.37–P05.41
-100.0%–100.0%
P05.39–10.00V
-100.0%–100.0%
0.000s–10.000s
-10.00V–P05.46
-100.0%–100.0%
Valid
Switch-off delay
Description
-115-
Goodrive3000 inverter
Invalid
Setting range Default
0.00–P05.34 0.00V
-100.0–100.0 0.0%
P05.32–10.00 10.00V
-100.0–100.0 100.0%
0.000–10.000 0.100s
-10.00V–P05.39 0.00V
-100.0–100.0 0.0%
P05.37–P05.41 0.00V
-100.0–100.0 0.0%
P05.39–10.00 10.00V
-100.0–100.0 100.0%
0.000–10.000 0.100s
-10.00–P05.46 -10.00V
-100.0–100.0 -100.0%
P05.44–P05.48 0.00V
