Goodrive3000 series medium voltage VFD
P10 group––Simple PLC and multi-step speed control
Function
Name
code
P10.00 Simple PLC
Set the simple PLC running mode.
0: Stop after running once: it is necessary to give the VFD the running command again after it finishes a
single cycle and automatically stops.
1: Run at the final value after running once: the VFD automatically keeps the running frequency and
direction of the last step after finishing a single cycle.
2: Cycle running: the VFD automatically enters into next cycle after finishing a single cycle and the
system will not stop until there is a stop command.
Function
Name
code
P10.01 Simple PLC memory
Set simple PLC memory manners when power loss.
0: Power loss without memory
1: Power loss with memory: PLC will memorize the running step and frequency when power loss.
Function
Name
code
P10.02 Multi-step speed 0
Running time of step
P10.03
0
P10.04 Multi-step speed 1
Running time of step
P10.05
1
P10.06 Multi-step speed 2
Running time of step
P10.07
2
P10.08 Multi-step speed 3
Description
0: Stop after running once
1: Run at the final value after running
once
2: Cycle running
Description
0: Power loss without memory
1: Power loss with memory
Description
-100.0–100.0%
0.0–6553.5s (min)
-100.0–100.0%
0.0–6553.5s (min)
-100.0–100.0%
0.0–6553.5s (min)
-100.0–100.0%
-150-
Goodrive3000 inverter
Setting range Default
0–2 0
Setting range Default
0–1 0
Setting range Default
-100.0–100.0 0.0%
0.0–6553.5 0.0s
-100.0–100.0 0.0%
0.0–6553.5 0.0s
-100.0–100.0 0.0%
0.0–6553.5 0.0s
-100.0–100.0 0.0%
