Goodrive3000 series medium voltage VFD
Function
Name
code
P06.19 AO3 output
P06.20 HDO pulse output
Instructions to output functions:
Set value
0 Running frequency
1
Description
2: Ramp reference frequency
3: Running rotating speed
4: Output current (Relative to VFD)
5: Output current (Relative to motor)
6: Output voltage
7: Output power
8: Set torque value
9: Output torque
10: AI1 input value
11: AI2 input value
12: AI3 input value
13: HDI pulse frequency input value
14: MODBUS communication set
value 1
15: MODBUS communication set
value 2
16: PROFIBUS/CANopen
communication set value 1
17: PROFIBUS/CANopen
communication set value 2
18: Ethernet communication set
value 1
19: Ethernet communication set
value 2
20: PID reference
21: PID feedback
22: Torque current (Relative to motor
rated current)
23: Ramp reference frequency (with
sign)
24–30: Reserved
Function
Set frequency
Instruction
0– Max. output frequency
0– Max. output frequency
-122-
Goodrive3000 inverter
Setting range Default
0–30 0
0–30 0
