INVT Goodrive3000 Series Operation Manual page 108

Goodrive3000 series medium voltage VFD
Function
Name
code
Motor 2 V/F curve
P04.13
setting
Motor 2 V/F torque
P04.14
boost
Motor 2 V/F torque
P04.15
boost close
Motor 2 V/F
P04.16
frequency point 1
Motor 2 V/F voltage
P04.17
point 1
Motor 2 V/F
P04.18
frequency point 2
Motor 2 V/F voltage
P04.19
point 2
Motor 2 V/F
P04.20
frequency point 3
Motor 2 V/F voltage
P04.21
point 3
Motor 2 V/F slip
P04.22
compensation gain
Motor 2 low
P04.23 frequency oscillation
control factor
Motor 2 high
P04.24 frequency oscillation
control factor
Description
0: Straight line V/F curve
1: Multi-dot V/F curve
2: Torque step-down V/F curve
(power of 1.3)
3: Torque step-down V/F curve
(power of 1.7)
4: Torque step-down V/F curve
(power of 2.0)
5: Customized V/F curve (V/F
separation)
0.0%: (Automatic) 0.1%–10.0%
0.0%–50.0% (Relative to rated
frequency of motor 2)
0.00Hz– P04.18
0.0%–110.0% (Rated voltage of
motor 2)
P04.16– P04.20
0.0%–110.0% (Rated voltage of
motor 2)
P04.18–P12.02 (Rated frequency of
motor 2)/P04.18–P12.16 (Rated
frequency of motor 2)
0.0%–110.0%(Rated voltage of the
motor 2)
0.0–200.0%
0–100
0–100
-103-
Goodrive3000 inverter
Setting range Default
0–5 0
0.0–10.0 0.0%
0.0–50.0 20.0%
0.00–P04.18 0.00Hz
0.0–110.0 00.0%
P04.16–P04.20 00.00Hz
0.0–110.0 00.0%
P04.18–P12.02/
00.00Hz
P04.18–P12.16
0.0–110.0 00.0%
0.0–200.0 100.0%
0–100 10
0–100 10
