Goodrive3000 series medium voltage VFD
Function
Name
code
switching-on
Delay time of RO2
P06.08
switching-off
Y Electrical
level
Y Valid
Function
Name
code
P06.13 AO1 output selection
P06.14 AO2 output selection
Function
Name
code
Lower output limit
P06.15
AO1
Lower limit
P06.16 corresponding AO1
output
Upper output limit
P06.17
AO1
Description
Invalid
Switch-on delay
Description
0: Null
1: The set value of the DC voltage
(AC1140V, 100% corresponds to
3000V)
2: The actual value of the DC voltage
(AC1140V, 100% corresponds to
3000V)
3: Valid value of input voltage (100%
corresponds to 2*Vn)
4: Valid value of input current (100%
corresponds to In*2)
5: Input power (100% corresponds to
2*Vn*In)
6: Input power factor (%)
7: Grid frequency value (100%
corresponds to 100.0Hz)
8–20: Reserved
Description
-100.0%–P06.17
-10.00V–10.00V
P06.15–100.0%
-37-
Goodrive3000 PWM rectifier
Setting range
Valid
Switch-off delay
Setting range
Setting range
-100.0%–P06.17
-10.00V–10.00V
P06.15–100.0%
Default
0.000s
Invalid
Default
1
0–20
2
Default
0.0%
0.00V
100.0%
