INVT Goodrive3000 Series Operation Manual page 70

Goodrive3000 series medium voltage VFD
Function
Name
code
selection
Lower output limit
P06.15
AO1
Lower limit
P06.16 corresponding AO1
output
Upper output limit
P06.17
AO1
Upper limit
P06.18 corresponding AO1
output
AO1 output filtering
P06.19
time
P06.20 Lower output limit 2 -100.0%–P06.22
Lower limit
P06.21 corresponding AO2
output
P06.22 Upper output limit 2 P06.20–100.0%
Upper limit
P06.23 corresponding AO2
output
AO2 output filtering
P06.24
time
Description
corresponds to 3000V)
2: The actual value of the DC
voltage (AC1140V, 100%
corresponds to 3000V)
3: Valid value of input voltage
(100% corresponds to 2*Vn)
4: Valid value of input current
(100% corresponds to In*2)
5: Input power (100%
corresponds to 2*Vn*In)
6: Input power factor (%)
7: Grid frequency value (100%
corresponds to 100.0Hz)
8–20: Reserved
-100.0%–P06.17
-10.00V–10.00V
P06.15–100.0%
-10.00V–10.00V
0.000–10.000s
-10.00–10.00V
-10.00V–10.00V
0.000–10.000s
-65-
Goodrive3000 PWM rectifier
Setting
Default
range
-100.0%–P06.17 0.0%
-10.0V–10.0V 0.00V
P06.15–100.0% 100.0%
-10.0V–10.00V 10.00V
0.000–10.000s 0.000s
-100.0%–P06.22 0.0%
-10.0V–10.00V 0.00V
P06.20–100.0% 100.0%
-10.0V–10.00V 10.00V
0.000–10.000s 0.000s
Modify
○
○
○
○
○
○
○
○
○
○
