Application Functions - Danfoss VLT FC 102 Programming Manual

Parameter Lists

5.1.20 22-** Application Functions

Parameter Parameter description
number
22-0* Miscellaneous
22-00 External Interlock Delay
22-01 Power Filter Time
22-1* Air Pres. to Flow
22-10 Air Pressure to Flow Signal source
22-11 Air Pressure to Flow Fan k-factor
22-12 Air Pressure to Flow Air density
22-13 Air Pressure to Flow Fan flow unit
5 5 22-2* No-Flow Detection
22-20 Low Power Auto Set-up
22-21 Low Power Detection
22-22 Low Speed Detection
22-23 No-Flow Function
22-24 No-Flow Delay
22-26 Dry Pump Function
22-27 Dry Pump Delay
22-3* No-Flow Power Tuning
22-30 No-Flow Power
22-31 Power Correction Factor
22-32 Low Speed [RPM]
22-33 Low Speed [Hz]
22-34 Low Speed Power [kW]
22-35 Low Speed Power [HP]
22-36 High Speed [RPM]
22-37 High Speed [Hz]
22-38 High Speed Power [kW]
22-39 High Speed Power [HP]
22-4* Sleep Mode
22-40 Minimum Run Time
22-41 Minimum Sleep Time
22-42 Wake-up Speed [RPM]
22-43 Wake-up Speed [Hz]
22-44 Wake-up Ref./FB Difference
22-45 Setpoint Boost
22-46 Maximum Boost Time
22-5* End of Curve
22-50 End of Curve Function
22-51 End of Curve Delay
22-52 End of Curve Tolerance
22-6* Broken Belt Detection
22-60 Broken Belt Function
22-61 Broken Belt Torque
22-62 Broken Belt Delay
22-7* Short Cycle Protection
22-75 Short Cycle Protection
22-76 Interval between Starts
22-77 Minimum Run Time
22-78 Minimum Run Time Override
22-79 Minimum Run Time Override Value
22-8* Flow Compensation
22-80 Flow Compensation
22-81 Square-linear Curve Approximation
22-82 Work Point Calculation
22-83 Speed at No-Flow [RPM]
22-84 Speed at No-Flow [Hz]
22-85 Speed at Design Point [RPM]
22-86 Speed at Design Point [Hz]
22-87 Pressure at No-Flow Speed
22-88 Pressure at Rated Speed
22-89 Flow at Design Point
22-90 Flow at Rated Speed
308
®
VLT HVAC Drive FC 102
Default value
0 s
0.50 s
[0] No function
1000 N/A
1.2 N/A
[0] m³/h
[0] Off
[0] Disabled
[0] Disabled
[0] Off
10 s
[0] Off
10 s
0 kW
100 %
ExpressionLimit
ExpressionLimit
ExpressionLimit
ExpressionLimit
ExpressionLimit
ExpressionLimit
ExpressionLimit
ExpressionLimit
10 s
10 s
ExpressionLimit
ExpressionLimit
10 %
0 %
60 s
[0] Off
10 s
2.5 %
[0] Off
10 %
10 s
[0] Disabled
start_to_start_min_on_time
(P2277)
0 s
[0] Disabled
0 ProcessCtrlUnit
[0] Disabled
100 %
[0] Disabled
ExpressionLimit
ExpressionLimit
ExpressionLimit
ExpressionLimit
0 N/A
999999.999 N/A
0 N/A
ExpressionLimit
Danfoss A/S © 10/2019 All rights reserved.
