Parameter Descriptions
16-77 Analog Out X30/8 [mA]
Range: Function:
0 [0 - 30 ] View the actual value at input
*
X30/8 in mA.
3.16.6 16-8* Fieldbus & FC Port
Parameters for reporting the bus references and control
words.
16-80 Fieldbus CTW 1
Range: Function:
0 [0 - 65535 ] View the 2-byte control word (CTW)
*
received from the fieldbus master.
Interpretation of the control word
depends on the fieldbus option
installed and the control word
profile selected in
parameter 8-10 Control Profile.
For more information, refer to the
relevant fieldbus manual.
16-82 Fieldbus REF 1
Range: Function:
0 [-200 - 200 ] View the 2-byte word sent with the
*
control word from the fieldbus
master to set the reference value.
For more information, refer to the
relevant fieldbus manual.
16-84 Comm. Option STW
Range: Function:
0 [0 - 65535 ] Show the status word of the
*
extended fieldbus communication
option.
For more information, refer to the
relevant fieldbus manual.
16-85 FC Port CTW 1
Range: Function:
0 [0 - 65535 ] View the 2-byte control word (CTW)
*
received from the fieldbus master.
Interpretation of the control word
depends on the fieldbus option
installed and the control word
profile selected in
parameter 8-10 Control Profile.
16-86 FC Port REF 1
Range: Function:
0 [-200 - 200 ] View the 2-byte status word (STW)
*
sent to the fieldbus master.
Interpretation of the status word
depends on the fieldbus option
installed and the control word
M0010001
Programming Guide
16-86 FC Port REF 1
Range:
3.16.7 16-9* Diagnosis Readouts
NOTICE
When using MCT 10 Set-up Software, the readout
parameters can only be read online, that is as the actual
status. This means that the status is not stored in the
MCT 10 Set-up Software file.
16-90 Alarm Word
Range:
0
*
16-91 Alarm Word 2
Range:
0
*
16-92 Warning Word
Range:
0
*
16-93 Warning Word 2
Range:
0
*
16-94 Ext. Status Word
Range:
0
*
16-95 Ext. Status Word 2
Range:
0
*
