Parameter Descriptions
35-46 Term. X48/2 Filter Time Constant
Range:
0.005 s
*
3 3
35-47 Term. X48/2 Live Zero
Option:
[0] Disabled
[1] Enabled
*
3.29 Parameters: 36-** Programmable I/O
Option
Parameters for configuring VLT
Parameters in this group are active only when VLT
Programmable I/O is installed.
3.29.1 36-0* I/O Mode
Use the parameters in this group to configure the mode of
inputs and outputs of VLT
Terminals can be programmed to provide voltage, current,
or digital output.
36-00 Terminal X49/1 Mode
Option:
[0] Current
[1] Voltage
*
[2] Pt 1000 [°C]
[3] Pt 1000 [°F]
[4] Ni 1000 [°C]
[5] Ni 1000 [°F]
36-01 Terminal X49/3 Mode
Option:
[0] Current
[1] Voltage
*
[2] Pt 1000 [°C]
[3] Pt 1000 [°F]
[4] Ni 1000 [°C]
[5] Ni 1000 [°F]
262
Function:
[0.005 - 10 s] Enter the filter time constant. This is
a first-order digital low-pass filter
time constant for suppressing
electrical noise in terminal X48/2. A
high time constant value improves
dampening but also increases the
time delay through the filter.
Function:
®
Programmable I/O .
®
Programmable I/O .
Function:
Select the mode of analog terminal
X49/1.
1000 Ω at 0°C
1000 Ω at 0°C
Function:
Select the mode of analog terminal
X49/3.
1000 Ω at 0°C
1000 Ω at 0°F
1000 Ω at 0°C
1000 Ω at 0°F
Danfoss A/S © 10/2019 All rights reserved.
®
VLT HVAC Drive FC 102
36-02 Terminal X49/5 Mode
Option:
[0]
[1]
*
[2]
[3]
[4]
[5]
36-03 Terminal X49/7 Mode
Select the output mode of analog terminal X49/7.
Option:
[0]
*
[1]
[2]
®
[3]
[4]
36-04 Terminal X49/9 Mode
Select the output mode of analog terminal X49/9.
Option:
[0]
*
[1]
[2]
[3]
[4]
36-05 Terminal X49/11 Mode
Select the output mode of analog terminal X49/11.
Option:
[0]
*
[1]
[2]
[3]
[4]
3.29.2 36-1* Analog Input X49/1
36-10 Terminal X49/1 Low Voltage
Range:
0.07 V
*
Function:
Select the mode of analog terminal
X49/5.
Current
Voltage
1000 Ω at 0°C
Pt 1000 [°C]
Pt 1000 [°F]
1000 Ω at 0°C
Ni 1000 [°C]
Ni 1000 [°F]
Function:
Voltage 0-10V
Voltage 2-10V
Current
0-20mA
Current
4-20mA
Digital
Function:
Voltage 0-10V
Voltage 2-10V
Current
0-20mA
Current
4-20mA
Digital
Function:
Voltage 0-10V
Voltage 2-10V
Current
0-20mA
Current
4-20mA
Digital
Function:
[ 0 - par. Enter the voltage that corresponds
36-12 V] to the low reference value in
parameter 36-14 Term. X49/1 Low
Ref./Feedb. Value.
