Parameter Descriptions
24-07 Fire Mode Feedback Source
Option: Function:
In fire mode closed-loop operation,
a feedback is requested for the
internal PID controller. Select the
feedback input to be used for the
feedback signal.
[0] No function
*
[1] Analog Input
53
[2] Analog Input
54
[3] Pulse input 29
[4] Pulse input 33
[7] Analog Input
X30/11
[8] Analog Input
X30/12
[9] Analog Input
X42/1
[10] Analog Input
X42/3
[11] Analog Input
X42/5
[15] Analog Input
X48/2
[16] Analog Input
X49/1
[17] Analog Input
X49/3
[18] Analog Input
X49/5
[19] Pressure 3
[20] Pressure 4
[99] Normal
Feedback
[100] Bus Feedback Different feedback channels can be
1 selected via fieldbus network.
[101] Bus Feedback Different feedback channels can be
2 selected via fieldbus network.
[102] Bus feedback Different feedback channels can be
3 selected via fieldbus network.
[104] Sensorless When feedback control must be
Flow related to water flow.
[105] Sensorless When feedback control must be
Pressure related to water pressure.
[110] Air Pres. to When feedback control must be
Flow related to air flow.
M0010001
Programming Guide
24-09 Fire Mode Alarm Handling
Option:
[0]
[1]
*
[2]
NOTICE
Warranty-affecting alarms. Certain alarms can affect the
lifetime of the frequency converter. Should 1 of these
ignored alarms occur while in fire mode, the alarms are
logged and stored in the fire mode-log.
NOTICE
The setting in parameter 14-20 Reset Mode is disregarded
if fire mode is active (see parameter group 24-0* Fire
Mode).
Danfoss A/S © 10/2019 All rights reserved.
Function:
Select an option to define the
response to alarms when fire mode
is active and an alarm is issued.
Trip+Reset, Alarms are ignored even though
Critical Alarms damage maybe caused, except for
the critical alarms mentioned in
Table 3.30. When these alarms
occur, the frequency converter trips
immediately, followed by an
automatic reset and restarts even if
the operation leads to an infinite
loop of trip and restart.
Trip, Critical Alarms are ignored even though
Alarms damage maybe caused, except for
the critical alarms mentioned in
Table 3.30. For the critical alarms, a
trip is caused. A manual reset is
required before restart. A manual
restart requires disabling fire mode
and enabling fire mode again.
Trip, All Option for testing fire mode
Alarms/Test operation without compromising
the normal handling of warnings
and alarms. All alarms are handled
as normally and defined in Table
4.1 Alarm/Warning Code List.
