Parameter Descriptions
16-46 Motor Phase V Current
Range:
0 A
*
3 3
16-47 Motor Phase W Current
Range:
0 A
*
16-49 Current Fault Source
Range:
0
*
After a short circuit alarm (I
(I ), or imbalance of supply voltage, this contains the
max1
power card number associated with the alarm. It only
holds 1 number indicating the highest priority power card
number (master first). The value persists on power cycle,
but if a new alarm occurs it is overwritten by the new
power card number (even if it is a lower priority number).
The value is only cleared when the alarm log is cleared
(that is a 3-finger reset would reset the readout to 0).
3.16.4 16-5* Ref. & Feedb.
16-50 External Reference
Range:
0
*
16-52 Feedback[Unit]
Range:
0
ProcessCtrl - 999999.999
Unit ProcessCtrlUnit
*
]
166
Function:
[0 - 10000 A] Shows the motor phase V
current. Facilitates monitoring of
imbalance in the motor currents,
detection of weak motor cables or
imbalance in motor windings.
Function:
[0 - 10000 A] Shows the motor phase W
current. Facilitates monitoring of
imbalance in the motor currents,
detection of weak motor cables or
imbalance in motor windings.
Function:
[0 - 8 ] The value indicates source of
current fault, including:
•
Short circuit.
•
Overcurrent.
•
Imbalance of supply
voltage (from left): 1–4 –
inverter, 5–8 – rectifier, 0 –
no fault recorded.
), or overcurrent alarm
max2
Function:
[-200 - 200 ] View the total reference, the sum of
digital, analog, preset, fieldbus, and
freeze references, plus catch up and
slow down.
Function:
[-999999.999 View value of resulting feedback
value after processing of feedback
1-3, see:
Danfoss A/S © 10/2019 All rights reserved.
®
VLT HVAC Drive FC 102
16-52 Feedback[Unit]
Range:
RMS
RMS
16-53 Digi Pot Reference
Range:
0
*
16-54 Feedback 1 [Unit]
Range:
0
ProcessCtrl
Unit
*
16-55 Feedback 2 [Unit]
Range:
0
ProcessCtrl
Unit
*
Function:
•
Parameter 16-54 Feedback
1 [Unit].
•
Parameter 16-55 Feedback
2 [Unit].
•
Parameter 16-56 Feedback
3 [Unit].
in the feedback manager.
See parameter group 20-0* Feedback.
The value is limited by settings in
parameter 3-02 Minimum Reference
and parameter 3-03 Maximum
Reference. Units as set in
parameter 20-12 Reference/Feedback
Unit.
Function:
[-200 - 200 ] View the contribution of the digital
potentiometer to the actual
reference.
Function:
[-999999.999 View value of feedback 1, see
- 999999.999 parameter group 20-0* Feedback.
ProcessCtrlUnit
The value is limited by settings in
]
parameter 20-13 Minimum Reference/
Feedb. and
parameter 20-14 Maximum
Reference/Feedb.. Units as set in
parameter 20-12 Reference/Feedback
Unit.
Function:
[-999999.999 View value of feedback 2, see
- 999999.999 parameter group 20-0* Feedback.
ProcessCtrlUnit
The value is limited by settings in
]
parameter 20-13 Minimum Reference/
Feedb. and
parameter 20-14 Maximum
Reference/Feedb. Units as set in
parameter 20-12 Reference/Feedback
Unit.
