Analog In / Out - Danfoss VLT FC 102 Programming Manual

Parameter Lists

5.1.8 6-** Analog In / Out

Paramet Parameter description
er
number
6-0* Analog I/O Mode
6-00 Live Zero Timeout Time
6-01 Live Zero Timeout Function
6-02 Fire Mode Live Zero Timeout Function
6-1* Analog Input 53
6-10 Terminal 53 Low Voltage
6-11 Terminal 53 High Voltage
6-12 Terminal 53 Low Current
6-13 Terminal 53 High Current
6-14 Terminal 53 Low Ref./Feedb. Value
6-15 Terminal 53 High Ref./Feedb. Value
6-16 Terminal 53 Filter Time Constant
6-17 Terminal 53 Live Zero
6-2* Analog Input 54
6-20 Terminal 54 Low Voltage
6-21 Terminal 54 High Voltage
6-22 Terminal 54 Low Current
6-23 Terminal 54 High Current
6-24 Terminal 54 Low Ref./Feedb. Value
6-25 Terminal 54 High Ref./Feedb. Value
6-26 Terminal 54 Filter Time Constant
6-27 Terminal 54 Live Zero
6-3* Analog Input X30/11
6-30 Terminal X30/11 Low Voltage
6-31 Terminal X30/11 High Voltage
6-34 Term. X30/11 Low Ref./Feedb. Value
6-35 Term. X30/11 High Ref./Feedb. Value
6-36 Term. X30/11 Filter Time Constant
6-37 Term. X30/11 Live Zero
6-4* Analog Input X30/12
6-40 Terminal X30/12 Low Voltage
6-41 Terminal X30/12 High Voltage
6-44 Term. X30/12 Low Ref./Feedb. Value
6-45 Term. X30/12 High Ref./Feedb. Value
6-46 Term. X30/12 Filter Time Constant
6-47 Term. X30/12 Live Zero
6-5* Analog Output 42
6-50 Terminal 42 Output
6-51 Terminal 42 Output Min Scale
6-52 Terminal 42 Output Max Scale
6-53 Terminal 42 Output Bus Control
6-54 Terminal 42 Output Timeout Preset
6-55 Analog Output Filter
6-6* Analog Output X30/8
6-60 Terminal X30/8 Output
6-61 Terminal X30/8 Min. Scale
6-62 Terminal X30/8 Max. Scale
6-63 Terminal X30/8 Output Bus Control
6-64 Terminal X30/8 Output Timeout Preset
6-7* Analog Output X45/1
6-70 Terminal X45/1 Output
6-71 Terminal X45/1 Min. Scale
6-72 Terminal X45/1 Max. Scale
6-73 Terminal X45/1 Bus Control
6-74 Terminal X45/1 Output Timeout Preset
6-8* Analog Output X45/3
6-80 Terminal X45/3 Output
6-81 Terminal X45/3 Min. Scale
6-82 Terminal X45/3 Max. Scale
6-83 Terminal X45/3 Bus Control
6-84 Terminal X45/3 Output Timeout Preset
M0010001
Programming Guide
Default value
10 s
[0] Off
[0] Off
0.07 V
10 V
4 mA
20 mA
ExpressionLimit
ExpressionLimit
0.005 s
[1] Enabled
0.07 V
10 V
4 mA
20 mA
0 N/A
100 N/A
0.005 s
[1] Enabled
0.07 V
10 V
0 N/A
100 N/A
0.005 s
[1] Enabled
0.07 V
10 V
0 N/A
100 N/A
0.005 s
[1] Enabled
ExpressionLimit
0 %
100 %
0 %
0 %
[0] Off
[0] No operation
0 %
100 %
0 %
0 %
[0] No operation
0 %
100 %
0 %
0 %
[0] No operation
0 %
100 %
0 %
0 %
Danfoss A/S © 10/2019 All rights reserved.
4-set-up Change Conver-
during sion index
operation
All set-ups TRUE
All set-ups TRUE
All set-ups TRUE
All set-ups TRUE
All set-ups TRUE
All set-ups TRUE
All set-ups TRUE
All set-ups TRUE
All set-ups TRUE
All set-ups TRUE
All set-ups TRUE
All set-ups TRUE
All set-ups TRUE
All set-ups TRUE
All set-ups TRUE
All set-ups TRUE
All set-ups TRUE
All set-ups TRUE
All set-ups TRUE
All set-ups TRUE
All set-ups TRUE
All set-ups TRUE
All set-ups TRUE
All set-ups TRUE
All set-ups TRUE
All set-ups TRUE
All set-ups TRUE
All set-ups TRUE
All set-ups TRUE
All set-ups TRUE
All set-ups TRUE
All set-ups TRUE
All set-ups TRUE
All set-ups TRUE
All set-ups TRUE
1 set-up TRUE
1 set-up TRUE
All set-ups TRUE
All set-ups TRUE
All set-ups TRUE
All set-ups TRUE
1 set-up TRUE
All set-ups TRUE
All set-ups TRUE
All set-ups TRUE
All set-ups TRUE
1 set-up TRUE
All set-ups TRUE
All set-ups TRUE
All set-ups TRUE
All set-ups TRUE
1 set-up TRUE
Type
0 Uint8
- Uint8
- Uint8
-2 Int16
-2 Int16
-5 Int16
-5 Int16 5 5
-3 Int32
-3 Int32
-3 Uint16
- Uint8
-2 Int16
-2 Int16
-5 Int16
-5 Int16
-3 Int32
-3 Int32
-3 Uint16
- Uint8
-2 Int16
-2 Int16
-3 Int32
-3 Int32
-3 Uint16
- Uint8
-2 Int16
-2 Int16
-3 Int32
-3 Int32
-3 Uint16
- Uint8
- Uint8
-2 Int16
-2 Int16
-2 N2
-2 Uint16
- Uint8
- Uint8
-2 Int16
-2 Int16
-2 N2
-2 Uint16
- Uint8
-2 Int16
-2 Int16
-2 N2
-2 Uint16
- Uint8
-2 Int16
-2 Int16
-2 N2
-2 Uint16
297
