13-40 Logic Rule Boolean 1
Array [6]
Option:
[95] RS Flipflop 1
[96] RS Flipflop 2
3 3
[97] RS Flipflop 3
[98] RS Flipflop 4
[99] RS Flipflop 5
[100] Fire Mode
[101] RS Flipflop 7
[103] Relay 1
[104] Relay 2
[109] Relay 7
[110] Relay 8
[111] Relay 9
[140] ATEX ETR cur.
warning
[141] ATEX ETR cur.
alarm
[142] ATEX ETR freq.
warning
[143] ATEX ETR freq.
alarm
[144] Pressure 1
Low
[145] Pressure 2
Low
[146] Pressure 3
Low
[147] Pressure 4
Low
[148] Pressure 1
High
[149] Pressure 2
High
[150] Pressure 3
High
[151] Pressure 4
High
13-41 Logic Rule Operator 1
Array [6]
Option:
138
®
VLT HVAC Drive FC 102
Function:
See parameter 13-15 RS-FF Operand
S and parameter 13-16 RS-FF
Operand R.
Function:
Select the 1 st logical operator to
use on the boolean inputs from
parameter 13-40 Logic Rule Boolean
1 and parameter 13-42 Logic Rule
Boolean 2.
Parameter numbers in square
brackets stand for the boolean
inputs of parameters in parameter
group 13-** Smart Logic Control.
Danfoss A/S © 10/2019 All rights reserved.
13-41 Logic Rule Operator 1
Array [6]
Option: Function:
[0] DISABLED Ignores:
[1] AND Evaluates the expression [13-40]
AND [13-42].
[2] OR Evaluates the expression [13-40] OR
[13-42].
[3] AND NOT Evaluates the expression [13-40]
AND NOT [13-42].
[4] OR NOT Evaluates the expression [13-40] OR
NOT [13-42].
[5] NOT AND Evaluates the expression NOT
[13-40] AND [13-42].
[6] NOT OR Evaluates the expression NOT
[13-40] OR [13-42].
[7] NOT AND NOT Evaluates the expression NOT
[13-40] AND NOT [13-42].
[8] NOT OR NOT Evaluates the expression NOT
[13-40] OR NOT [13-42].
13-42 Logic Rule Boolean 2
Array [6]
Option: Function:
Select the 2
false) input for the selected logic
rule.
See parameter 13-40 Logic Rule
Boolean 1 for further descriptions of
options and their functions.
[0] False
[1] True
[2] Running
[3] In range
[4] On reference
[5] Torque limit
[6] Current Limit
[7] Out of current
range
[8] Below I low
[9] Above I high
[10] Out of speed
range
[11] Below speed
low
•
Parameter 13-42 Logic Rule
Boolean 2.
•
Parameter 13-43 Logic Rule
Operator 2.
•
Parameter 13-44 Logic Rule
Boolean 3.
nd
boolean (true or
