Parameter Descriptions
24-01 Fire Mode Configuration
Option: Function:
NOTICE
Before adjusting the PID
controller set
parameter 24-09 Fire Mode
Alarm Handling, [2] Trip, All
Alarms/Test.
NOTICE
If [2] Enable-Run Reverse is
selected in
parameter 24-00 Fire Mode
Function, [3] Closed Loop
cannot be selected in
parameter 24-01 Fire Mode
Configuration.
The fire mode can be controlled in
open loop with up to 8 different
preset values (zones), or in close
loop by an reference and feedback
signal. The reference and feedback
signal can come via drive input
signals or over the fieldbus.
[0] Open Loop When fire mode is active, the motor
*
runs with a fixed speed based on a
reference set. The unit is the same
as selected in parameter 0-02 Motor
Speed Unit.
[3] Closed Loop When fire mode is active, the built-
in PID controller controls the speed
based on the setpoint and a
feedback signal selected in
parameter 24-07 Fire Mode Feedback
Source. Select the unit in
parameter 24-02 Fire Mode Unit. For
PID controller settings use
parameter group 20-** FC Closed
Loop as for normal operation. The
same PID configuration can be
selected for both normal, and fire
mode, and the operation can be
continued as setup 1 to 4.
24-02 Fire Mode Unit
Option: Function:
By default, fire mode is configured
for open-loop control where only
the motor unit is selected in
parameter 0-02 Motor Speed Unit.
For closed-loop operation, select
any of the following options.
[0] None
M0010001
Programming Guide
24-02 Fire Mode Unit
Option:
[1]
[2]
[3]
[4]
[5]
[10]
[11]
[12]
[20]
[21]
[22]
[23]
[24]
[25]
[30]
[31]
[32]
[33]
[34]
[40]
[41]
[45]
[60]
[70]
[71]
[72]
[73]
[74]
[75]
[80]
[120]
[121]
[122]
[123]
[124]
[125]
[126]
[127]
[130]
[131]
[132]
[140]
[141]
[145]
[160]
[170]
[171]
[172]
[173]
[174]
[180]
Danfoss A/S © 10/2019 All rights reserved.
Function:
%
RPM
Hz
Nm
PPM
1/min
RPM
Pulse/s
l/s
l/min
l/h
m³/s
m³/min
m³/h
kg/s
kg/min
kg/h
t/min
t/h
m/s
m/min
m
°C
mbar
bar
Pa
kPa
m WG
mm Hg
kW
GPM
gal/s
gal/min
gal/h
CFM
ft³/s
ft³/min
ft³/h
lb/s
lb/min
lb/h
ft/s
ft/min
ft
°F
psi
lb/in²
in WG
ft WG
in Hg
HP
