Parameter Descriptions
8-13 Configurable Status Word STW
This parameter enables configuration of bits 12–15 in the status
word.
Array [16]
Option:
3
3
[0]
No function
[1]
Profile Default
*
[2]
Alarm 68 Only Only set if alarm 68, Safe Torque Off
[3]
Trip excl
Alarm 68
[10]
T18 DI status
[11]
T19 DI status
[12]
T27 DI status
[13]
T29 DI status
[14]
T32 DI status
[15]
T33 DI status
[16]
T37 DI status
[17]
X30/2 DI
status
116
®
VLT
HVAC Drive FC 102
Function:
The function corresponds to the
profile default selected in
parameter 8-10 Control Profile.
occurs.
Set if a trip occurs, unless alarm 68,
Safe Torque Off is set to execute the
trip.
The bit indicates the status of
terminal 18.
0 indicates that the terminal is low.
1 indicates that the terminal is
high.
The bit indicates the status of
terminal 19.
0 indicates that the terminal is low.
1 indicates that the terminal is
high.
The bit indicates the status of
terminal 27.
0 indicates that the terminal is low.
1 indicates that the terminal is
high.
The bit indicates the status of
terminal 29.
0 indicates that the terminal is low.
1 indicates that the terminal is
high.
The bit indicates the status of
terminal 32.
0 indicates that the terminal is low.
1 indicates that the terminal is
high.
The bit indicates the status of
terminal 33.
0 indicates that the terminal is low.
1 indicates that the terminal is
high.
The bit indicates the status of
terminal 37.
0 indicates that T37 is low (Safe
Torque Off).
1 indicates that T37 is high
(normal).
Danfoss A/S © 10/2019 All rights reserved.
8-13 Configurable Status Word STW
This parameter enables configuration of bits 12–15 in the status
word.
Array [16]
Option:
Function:
[18]
X30/3 DI
status
[19]
X30/4 DI
status
[21]
Thermal
The thermal warning turns on when
warning
the temperature exceeds the limit
in the motor, frequency converter,
brake resistor, or thermistor.
[30]
Brake fault
Output is logic 1 when the brake
(IGBT)
IGBT is short-circuited. Use this
function to protect the frequency
converter if there is a fault on the
brake modules. Use the output/
relay to cut out the main voltage
from the frequency converter.
[40]
Out of ref
range
[49]
Derate active
[54]
Running
[59]
On Reference
[60]
Comparator 0
See parameter group 13-1*
Comparators. If comparator 0 is
evaluated as true, the output goes
high. Otherwise, it is low.
[61]
Comparator 1
See parameter group 13-1*
Comparators. If comparator 1 is
evaluated as true, the output goes
high. Otherwise, it is low.
[62]
Comparator 2
See parameter group 13-1*
Comparators. If comparator 2 is
evaluated as true, the output goes
high. Otherwise, it is low.
[63]
Comparator 3
See parameter group 13-1*
Comparators. If comparator 3 is
evaluated as true, the output goes
high. Otherwise, it is low.
[64]
Comparator 4
See parameter group 13-1*
Comparators. If comparator 4 is
evaluated as true, the output goes
high. Otherwise, it is low.
[65]
Comparator 5
See parameter group 13-1*
Comparators. If comparator 5 is
evaluated as true, the output goes
high. Otherwise, it is low.
[70]
Logic Rule 0
See parameter group 13-4* Logic
Rules. If logic rule 0 is evaluated as
true, the output goes high.
Otherwise, it is low.
M0010001
