Danfoss VLT FC 102 Programming Manual page 269

Parameter Descriptions
36-43 Terminal X49/7 Max. Scale
Range: Function:
parameter 6-52 Terminal 42 Output
Max Scale
Example
Parameter 36-03 Terminal X49/7
Mode=[0] Voltage 0-10 V
Parameter 36-40 Terminal X49/7
Analogue Output=[100] Output
frequency
Parameter 4-19 Max Output
Frequency=200 Hz
Example case 1: 5 V maximum
output is required when the output
frequency is 200 Hz.
Parameter 36-43 Terminal X49/7 Max.
Scale = (10 V/5 V) x 100% = 200%.
Example case 2: 10 V maximum
output is required when the output
frequency is 150 Hz (75% of the
maximum output frequency).
Parameter 36-43 Terminal X49/7 Max.
Scale = 75%.
36-44 Terminal X49/7 Bus Control
Range: Function:
0 % [0 - 100 %] This parameter contains the output
*
level of terminal X49/7 if the
terminal is controlled by a fieldbus.
36-45 Terminal X49/7 Timeout Preset
Range: Function:
0 % [0 - 100 %] The frequency converter sends the
*
value of this parameter to the
output terminal when the terminal
is controlled by a fieldbus and a
timeout is detected.
3.29.6 36-5* Output X49/9
Use the parameters in this group to configure the mode of
®
inputs and outputs of VLT Programmable I/O .
36-50 Terminal X49/9 Analogue Output
Select the functionality of terminal X49/9.
Option: Function:
[0] No operation
*
[52] MCO 0-20mA/
0-10V
[86] Pressure
Sensor 1
[88] Pressure
Sensor 2
[93] Pressure
Sensor 3
M0010001
Programming Guide
36-50 Terminal X49/9 Analogue Output
Select the functionality of terminal X49/9.
Option:
[100]
[101]
[102]
[103]
[104]
[105]
[106]
[107]
[113]
[114]
[115]
[121]
[139]
[141]
[186]
36-51 Terminal X49/9 Digital Output
Select the function of Terminal X49/9 as an analog voltage
output.
Option:
[0]
*
[1]
[2]
[3]
[4]
[5]
[6]
[8]
[9]
[10]
[11]
[12]
[13]
Danfoss A/S © 10/2019 All rights reserved.
Function:
Output freq.
0-100
Reference
Min-Max
Feedback
+-200%
Motor cur. 0-
Imax
Torque 0-Tlim
Torque 0-
Tnom
Power 0-Pnom
Speed 0-
HighLim
Ext. Closed
Loop 1
Ext. Closed
Loop 2
Ext. Closed
Loop 3
Air pres. to
Flow
Bus ctrl.
Bus ctrl t.o.
Pressure
Sensor 4
Function:
No operation
Control Ready
Drive ready
Drive rdy/rem
ctrl
Standby / no
warning
Running
Running / no
warning
Run on ref/no
warn
Alarm
Alarm or
warning
At torque limit
Out of current
range
Below current,
low
3 3
