6. How to programme the frequency converter
Group no.
0
1
2
3
4
5
6
8
9
10
11
13
14
15
16
18
20
21
22
23
24
25
26
6
Table 6.3: Parameter groups.
After selecting a parameter group, choose a parameter by means of the
navigation keys.
The middle section on the GLCP display shows the parameter number and
name as well as the selected parameter value.
6.1.7. Changing Data
1. Press [Quick Menu] or [Main Menu] key.
2. Use [ ] and [ ] keys keys to find parameter group to edit.
▲
3. Use [ ] and [ ] keys to find parameter to edit.
▲
4. Press [OK] key.
5. Use [ [ ] and [ ] keys to select correct parameter setting. Or, to move to digits within a number, use keys. Cursor indicates digit selected to
▲
change. [ ] key increases the value, [ ] key decreases the value.
▲
6. Press [Cancel] key to disregard change, or press [OK] key to accept change and enter new setting.
100
Parameter group:
Operation/Display
Load/Motor
Brakes
References/Ramps
Limits/Warnings
Digital In/Out
Analog In/Out
Comm. and Options

Profibus

CAN Fieldbus

LonWorks

Smart Logic

Special Functions

Drive Information

Data Readouts

Data Readouts 2
Drive Closed Loop
Ext. Closed Loop

Application Functions

Time-based Functions
Fire Mode

Cascade Controller

Analog I/O Option MCB 109

▲
▲
▲
▲
MG.11.A6.02 - VLT
®
VLT HVAC Drive Operating Instructions
Illustration 6.10: Display example.
