Parameter Lists

5.1.19 21-** Ext. Closed Loop

Parameter Parameter description
number
21-0* Ext. CL Autotuning
21-00 Closed Loop Type
21-01 PID Performance
21-02 PID Output Change
21-03 Minimum Feedback Level
21-04 Maximum Feedback Level
21-09 PID Autotuning
21-1* Ext. CL 1 Ref./Fb.
21-10 Ext. 1 Ref./Feedback Unit
21-11 Ext. 1 Minimum Reference
21-12 Ext. 1 Maximum Reference
21-13 Ext. 1 Reference Source
21-14 Ext. 1 Feedback Source
21-15 Ext. 1 Setpoint
21-17 Ext. 1 Reference [Unit]
21-18 Ext. 1 Feedback [Unit]
21-19 Ext. 1 Output [%]
21-2* Ext. CL 1 PID
21-20 Ext. 1 Normal/Inverse Control
21-21 Ext. 1 Proportional Gain
21-22 Ext. 1 Integral Time
21-23 Ext. 1 Differentation Time
21-24 Ext. 1 Dif. Gain Limit
21-26 Ext. 1 On Reference Bandwidth
21-3* Ext. CL 2 Ref./Fb.
21-30 Ext. 2 Ref./Feedback Unit
21-31 Ext. 2 Minimum Reference
21-32 Ext. 2 Maximum Reference
21-33 Ext. 2 Reference Source
21-34 Ext. 2 Feedback Source
21-35 Ext. 2 Setpoint
21-37 Ext. 2 Reference [Unit]
21-38 Ext. 2 Feedback [Unit]
21-39 Ext. 2 Output [%]
21-4* Ext. CL 2 PID
21-40 Ext. 2 Normal/Inverse Control
21-41 Ext. 2 Proportional Gain
21-42 Ext. 2 Integral Time
21-43 Ext. 2 Differentation Time
21-44 Ext. 2 Dif. Gain Limit
21-46 Ext. 2 On Reference Bandwidth
21-5* Ext. CL 3 Ref./Fb.
21-50 Ext. 3 Ref./Feedback Unit
21-51 Ext. 3 Minimum Reference
21-52 Ext. 3 Maximum Reference
21-53 Ext. 3 Reference Source
21-54 Ext. 3 Feedback Source
21-55 Ext. 3 Setpoint
21-57 Ext. 3 Reference [Unit]
21-58 Ext. 3 Feedback [Unit]
21-59 Ext. 3 Output [%]
21-6* Ext. CL 3 PID
21-60 Ext. 3 Normal/Inverse Control
21-61 Ext. 3 Proportional Gain
21-62 Ext. 3 Integral Time
21-63 Ext. 3 Differentation Time
21-64 Ext. 3 Dif. Gain Limit
21-66 Ext. 3 On Reference Bandwidth
M0010001
Programming Guide
Default value
[0] Auto
[0] Normal
0.10 N/A
-999999 N/A
999999 N/A
[0] Disabled
[1] %
0 ExtPID1Unit
100 ExtPID1Unit
[0] No function
[0] No function
0 ExtPID1Unit
0 ExtPID1Unit
0 ExtPID1Unit
0 %
[0] Normal
0.01 N/A
10000 s
0 s
5 N/A
5 %
[1] %
0 ExtPID2Unit
100 ExtPID2Unit
[0] No function
[0] No function
0 ExtPID2Unit
0 ExtPID2Unit
0 ExtPID2Unit
0 %
[0] Normal
0.01 N/A
10000 s
0 s
5 N/A
5 %
[1] %
0 ExtPID3Unit
100 ExtPID3Unit
[0] No function
[0] No function
0 ExtPID3Unit
0 ExtPID3Unit
0 ExtPID3Unit
0 %
[0] Normal
0.01 N/A
10000 s
0 s
5 N/A
5 %
Danfoss A/S © 10/2019 All rights reserved.
4-set-up Change Conver-
during sion index
operation
2 set-ups TRUE
2 set-ups TRUE
2 set-ups TRUE -2
2 set-ups TRUE -3
2 set-ups TRUE -3
All set-ups TRUE
All set-ups TRUE
All set-ups TRUE -3
All set-ups TRUE -3
All set-ups TRUE
All set-ups TRUE
All set-ups TRUE -3
All set-ups TRUE -3
All set-ups TRUE -3
All set-ups TRUE 0
All set-ups TRUE
All set-ups TRUE -2
All set-ups TRUE -2
All set-ups TRUE -2
All set-ups TRUE -1
All set-ups TRUE 0
All set-ups TRUE
All set-ups TRUE -3
All set-ups TRUE -3
All set-ups TRUE
All set-ups TRUE
All set-ups TRUE -3
All set-ups TRUE -3
All set-ups TRUE -3
All set-ups TRUE 0
All set-ups TRUE
All set-ups TRUE -2
All set-ups TRUE -2
All set-ups TRUE -2
All set-ups TRUE -1
All set-ups TRUE 0
All set-ups TRUE
All set-ups TRUE -3
All set-ups TRUE -3
All set-ups TRUE
All set-ups TRUE
All set-ups TRUE -3
All set-ups TRUE -3
All set-ups TRUE -3
All set-ups TRUE 0
All set-ups TRUE
All set-ups TRUE -2
All set-ups TRUE -2
All set-ups TRUE -2
All set-ups TRUE -1
All set-ups TRUE 0
Type
- Uint8
- Uint8
Uint16
Int32
Int32
- Uint8
- Uint8 5 5
Int32
Int32
- Uint8
- Uint8
Int32
Int32
Int32
Int32
- Uint8
Uint16
Uint32
Uint16
Uint16
Uint8
- Uint8
Int32
Int32
- Uint8
- Uint8
Int32
Int32
Int32
Int32
- Uint8
Uint16
Uint32
Uint16
Uint16
Uint8
- Uint8
Int32
Int32
- Uint8
- Uint8
Int32
Int32
Int32
Int32
- Uint8
Uint16
Uint32
Uint16
Uint16
Uint8
