Parameter Descriptions
26-36 Term. X42/5 Filter Time Constant
Range: Function:
NOTICE
0.005 s [0.005 - 10 s]
*
This parameter cannot be
adjusted while the motor is
running.
This is a first-order digital low-pass
filter time constant for suppressing
noise in terminal X42/5. A high
time constant value improves
dampening, but also increases the
time delay through the filter.
26-37 Term. X42/5 Live Zero
Option: Function:
Enable or disable the live zero
monitoring.
[0] Disabled
[1] Enabled
*
3.24.5 26-4* Analog Out X42/7
Parameters for configuring the scaling and output function
for analog output, terminal X42/7.
26-40 Terminal X42/7 Output
Option: Function:
Set the function of terminal X42/7
as an analog current output.
[0] No operation
*
[52] MCO 0-20mA/
0-10V
[86] Pressure
Sensor 1
[88] Pressure
Sensor 2
[93] Pressure
Sensor 3
[100] Output freq. 0–100 Hz, (0–10 V).
0-100
[101] Reference Minimum reference–maximum
Min-Max reference, (0–10 V).
[102] Feedback -200% to +200% of
+-200% parameter 3-03 Maximum Reference,
(0–10 V).
[103] Motor cur. 0- 0–inverter maximum current
Imax (parameter 16-37 Inv. Max. Current),
(0–10 V).
[104] Torque 0-Tlim 0–torque limit
(parameter 4-16 Torque Limit Motor
Mode), (0–10 V).
M0010001
Programming Guide
26-40 Terminal X42/7 Output
Option:
[105]
[106]
[107]
[113]
[114]
[115]
[121]
[139]
[141]
[186]
26-41 Terminal X42/7 Min. Scale
Range:
0 %
*
Danfoss A/S © 10/2019 All rights reserved.
Function:
Torque 0- 0–motor rated torque, (0–10 V).
Tnom
Power 0-Pnom 0–motor rated power, (0–10 V).
Speed 0- 0–speed high limit
HighLim (parameter 4-13 Motor Speed High
Limit [RPM] and
parameter 4-14 Motor Speed High
Limit [Hz]), (0–10 V).
Ext. Closed 0–100%, (0–10 V).
Loop 1
Ext. Closed 0–100%, (0–10 V).
Loop 2
Ext. Closed 0–100%, (0–10 V).
Loop 3
Air pres. to
Flow
Bus ctrl. 0–100%, (0–10 V).
Bus ctrl t.o. 0–100%, (0–10 V).
Pressure
Sensor 4
Function:
[0 - 200 %] Scale the minimum output of the
selected analog signal at terminal
X42/7 as a percentage of the
maximum signal level. For example,
if 0 V (or 0 Hz) is required at 25%
of the maximum output value,
program 25%. Scaling values up to
100% can never be higher than the
corresponding setting in
parameter 26-42 Terminal X42/7 Max.
Scale.
See principle graph for
parameter 6-51 Terminal 42 Output
Min Scale.
