Parameter Descriptions
16-12 Motor Voltage
Range:
0 V
*
3 3
16-13 Frequency
Range:
0 Hz
*
16-14 Motor current
Range:
0 A
*
16-15 Frequency [%]
Range:
0 %
*
100 %]
16-16 Torque [Nm]
Range:
0 Nm
*
30000 Nm]
16-17 Speed [RPM]
Range:
0 RPM
*
30000 RPM]
164
Function:
[0 - 6000 V] View the motor voltage, a
calculated value used for
controlling the motor.
Function:
[0 - 6500 Hz] View the motor frequency without
resonance damping.
Function:
[0 - 10000 A] View the motor current measured
as an average value, I
is filtered, and thus approximately
1.3 s may pass from when an input
value changes to when the data
readout values change.
Function:
[-100 - View a 2-byte word reporting the
actual motor frequency (without
resonance damping) as a
percentage (scale 0000–4000 hex)
of parameter 4-19 Max Output
Frequency. Set parameter 9-16 PCD
Read Configuration index 1 to send
it with the status word instead of
the MAV.
Function:
[-30000 - View the torque value with sign,
applied to the motor shaft. Linearity
is not exact between 110% motor
current and torque in relation to
the rated torque. Some motors
supply more than 160% torque.
Therefore, the minimum and the
maximum values depend on the
maximum motor current and the
motor used. The value is filtered,
and thus approximately 1.3 s may
pass from when an input changes
value to when the data readout
values change.
Function:
[-30000 - View the actual motor RPM.
Danfoss A/S © 10/2019 All rights reserved.
®
VLT HVAC Drive FC 102
16-18 Motor Thermal
Range:
0 %
*
16-19 Thermistor Sensor Temperature
Range:
0 °C
*
. The value
RMS
16-22 Torque [%]
Range:
0 %
*
16-26 Power Filtered [kW]
Range:
0 kW
*
16-27 Power Filtered [hp]
Range:
0 hp
*
Function:
[0 - 100 %] View the calculated thermal load on
the motor. The cutout limit is 100%.
The basis for calculation is the ETR
function selected in
parameter 1-90 Motor Thermal
Protection.
Function:
[0 - 0 °C] Returning the actual temperature
on KTY sensor built into the motor.
See parameter group 1-9* Motor
Temperature.
Function:
[-200 - This is a readout parameter only.
200 %] Shows the actual torque yielded in
percentage of the rated torque,
based on the setting of the motor
size and rated speed in
parameter 1-20 Motor Power [kW] or
parameter 1-21 Motor Power [HP],
and parameter 1-25 Motor Nominal
Speed.
This is the value monitored by the
broken-belt function set in
parameter group 22-6* Broken Belt
Detection.
Function:
[0 - 10000 Motor power consumption. The
kW] value shown is calculated on basis
of the actual motor voltage and
motor current. The value is filtered,
and a few seconds may pass from
when an input value changes to
when the data readout values
change.
Function:
[0 - 10000 Motor power in hp. The value
hp] shown is calculated on the basis of
actual motor voltage and motor
current. The value is filtered, and a
few seconds may pass from when
an input value changes to when
the data readout values change.
M0010001
