Danfoss VLT FC 102 Programming Manual page 267

Parameter Descriptions
36-40 Terminal X49/7 Analogue Output
Option: Function:
[107] Speed 0-
HighLim
[113] Ext. Closed
Loop 1
[114] Ext. Closed
Loop 2
[115] Ext. Closed
Loop 3
[121] Air pres. to
Flow
[139] Bus ctrl.
[141] Bus ctrl t.o.
[186] Pressure
Sensor 4
36-41 Terminal X49/7 Digital Output
Select the function of Terminal X49/7 as a digital output.
Option: Function:
[0] No operation
*
[1] Control Ready
[2] Drive ready
[3] Drive rdy/rem
ctrl
[4] Standby / no
warning
[5] Running
[6] Running / no
warning
[8] Run on ref/no
warn
[9] Alarm
[10] Alarm or
warning
[11] At torque limit
[12] Out of current
range
[13] Below current,
low
[14] Above current,
high
[15] Out of speed
range
[16] Below speed,
low
[17] Above speed,
high
[18] Out of feedb.
range
[19] Below
feedback, low
[20] Above
feedback, high
M0010001
Programming Guide
36-41 Terminal X49/7 Digital Output
Select the function of Terminal X49/7 as a digital output.
Option:
[21]
[25]
[26]
[27]
[28]
[29]
[30]
[31]
[33]
[35]
[40]
[41]
[42]
[45]
[46]
[47]
[51]
[59]
[60]
[61]
[62]
[63]
[64]
[65]
[70]
[71]
[72]
[73]
[74]
[75]
[80]
[81]
[82]
[83]
Danfoss A/S © 10/2019 All rights reserved.
Function:
Thermal
warning
Reverse
Bus OK
Torque limit &
stop
Brake, no
brake war
Brake ready,
no fault
Brake fault
(IGBT)
Relay 123
Safe stop
active
External
Interlock
Out of ref
range
Below
reference, low
Above ref,
high
Bus ctrl.
Bus ctrl, 1 if
timeout
Bus ctrl, 0 if
timeout
MCO
controlled
Remote,enable
,no TW
Comparator 0
Comparator 1
Comparator 2
Comparator 3
Comparator 4
Comparator 5
Logic rule 0
Logic rule 1
Logic rule 2
Logic rule 3
Logic rule 4
Logic rule 5
SL digital
output A
SL digital
output B
SL digital
output C
SL digital
output D
3 3
