5.1.24 26-** Analog I / O Option MCB 109

Parameter Parameter description
number
26-0* Analog I/O Mode
26-00 Terminal X42/1 Mode
26-01 Terminal X42/3 Mode
26-02 Terminal X42/5 Mode
26-1* Analog Input X42/1
26-10 Terminal X42/1 Low Voltage
26-11 Terminal X42/1 High Voltage
26-14 Term. X42/1 Low Ref./Feedb. Value
5 5 26-15 Term. X42/1 High Ref./Feedb. Value
26-16 Term. X42/1 Filter Time Constant
26-17 Term. X42/1 Live Zero
26-2* Analog Input X42/3
26-20 Terminal X42/3 Low Voltage
26-21 Terminal X42/3 High Voltage
26-24 Term. X42/3 Low Ref./Feedb. Value
26-25 Term. X42/3 High Ref./Feedb. Value
26-26 Term. X42/3 Filter Time Constant
26-27 Term. X42/3 Live Zero
26-3* Analog Input X42/5
26-30 Terminal X42/5 Low Voltage
26-31 Terminal X42/5 High Voltage
26-34 Term. X42/5 Low Ref./Feedb. Value
26-35 Term. X42/5 High Ref./Feedb. Value
26-36 Term. X42/5 Filter Time Constant
26-37 Term. X42/5 Live Zero
26-4* Analog Out X42/7
26-40 Terminal X42/7 Output
26-41 Terminal X42/7 Min. Scale
26-42 Terminal X42/7 Max. Scale
26-43 Terminal X42/7 Bus Control
26-44 Terminal X42/7 Timeout Preset
26-5* Analog Out X42/9
26-50 Terminal X42/9 Output
26-51 Terminal X42/9 Min. Scale
26-52 Terminal X42/9 Max. Scale
26-53 Terminal X42/9 Bus Control
26-54 Terminal X42/9 Timeout Preset
26-6* Analog Out X42/11
26-60 Terminal X42/11 Output
26-61 Terminal X42/11 Min. Scale
26-62 Terminal X42/11 Max. Scale
26-63 Terminal X42/11 Bus Control
26-64 Terminal X42/11 Timeout Preset
312
®
VLT HVAC Drive FC 102
Default value
[1] Voltage
[1] Voltage
[1] Voltage
0.07 V
10 V
0 N/A
100 N/A
0.005 s
[1] Enabled
0.07 V
10 V
0 N/A
100 N/A
0.005 s
[1] Enabled
0.07 V
10 V
0 N/A
100 N/A
0.005 s
[1] Enabled
[0] No operation
0 %
100 %
0 %
0 %
[0] No operation
0 %
100 %
0 %
0 %
[0] No operation
0 %
100 %
0 %
0 %
Danfoss A/S © 10/2019 All rights reserved.
4-set-up Change Conver-
during sion index
operation
All set-ups TRUE
All set-ups TRUE
All set-ups TRUE
All set-ups TRUE -2
All set-ups TRUE -2
All set-ups TRUE -3
All set-ups TRUE -3
All set-ups TRUE -3
All set-ups TRUE
All set-ups TRUE -2
All set-ups TRUE -2
All set-ups TRUE -3
All set-ups TRUE -3
All set-ups TRUE -3
All set-ups TRUE
All set-ups TRUE -2
All set-ups TRUE -2
All set-ups TRUE -3
All set-ups TRUE -3
All set-ups TRUE -3
All set-ups TRUE
All set-ups TRUE
All set-ups TRUE -2
All set-ups TRUE -2
All set-ups TRUE -2
1 set-up TRUE -2
All set-ups TRUE
All set-ups TRUE -2
All set-ups TRUE -2
All set-ups TRUE -2
1 set-up TRUE -2
All set-ups TRUE
All set-ups TRUE -2
All set-ups TRUE -2
All set-ups TRUE -2
1 set-up TRUE -2
Type
- Uint8
- Uint8
- Uint8
Int16
Int16
Int32
Int32
Uint16
- Uint8
Int16
Int16
Int32
Int32
Uint16
- Uint8
Int16
Int16
Int32
Int32
Uint16
- Uint8
- Uint8
Int16
Int16
N2
Uint16
- Uint8
Int16
Int16
N2
Uint16
- Uint8
Int16
Int16
N2
Uint16
M0010001
