Parameter Descriptions
•
Parameter 13-90 Alert Trigger = [37] Digital input
DI32.
•
Parameter 13-91 Alert Action = [5] Stop & warning.
•
Parameter 13-92 Alert Text = Valve 5 open.
13-90 Alert Trigger
Array [10]
Select the event that triggers the user-defined action and
message.
Option: Function:
[0] False
*
[1] True
[18] Reversing
[22] Comparator 0
[23] Comparator 1
[24] Comparator 2
[25] Comparator 3
[26] Logic rule 0
[27] Logic rule 1
[28] Logic rule 2
[29] Logic rule 3
[30] SL Time-out 0
[31] SL Time-out 1
[32] SL Time-out 2
[33] Digital input
DI18
[34] Digital input
DI19
[35] Digital input
DI27
[36] Digital input
DI29
[37] Digital input
DI32
[38] Digital input
DI33
[50] Comparator 4
[51] Comparator 5
[60] Logic rule 4
[61] Logic rule 5
[70] SL Time-out 3
[71] SL Time-out 4
[72] SL Time-out 5
[73] SL Time-out 6
[74] SL Time-out 7
[90] ECB Drive
Mode
[91] ECB Bypass
Mode
[144] Pressure 1
Low
[145] Pressure 2
Low
[146] Pressure 3
Low
M0010001
Programming Guide
13-90 Alert Trigger
Array [10]
Select the event that triggers the user-defined action and
message.
Option:
[147]
[148]
[149]
[150]
[151]
13-91 Alert Action
Array [10]
Select the action that the frequency converter performs when
the event defined in parameter 13-90 Alert Trigger occurs.
Option:
[0]
*
[1]
[2]
[3]
[4]
[5]
[6]
[7]
[8]
[9]
[10]
[11]
[12]
[13]
[14]
13-92 Alert Text
Range:
Size
related
*
Danfoss A/S © 10/2019 All rights reserved.
Function:
Pressure 4
Low
Pressure 1
High
Pressure 2
High
Pressure 3
High
Pressure 4
High
Function:
Info
Warning
Freeze output
Freeze output
& warn
Stop
Stop &
warning
Jogging
Jogging &
warning
Max speed
Max speed &
warn
Stop and trip
Stop and trip
w manual
reset
Trip
Trip w manual
reset
Trip Lock
Function:
[0 - 20 ] Array [10]
Enter the text that the frequency
converter shows in the display
when the event defined in
parameter 13-90 Alert Trigger occurs.
